CONSOLE для Polaris 600 CLASSIC (S04ND6ES) - 2004 года выпуска

  • №
    Артикул
    Название
  • 1
    4010597 CONTROLLER M-10 ACE, ELECTRIC
    CONTROLLER M-10 ACE, ELECTRIC
  • 2
    7541925 NUT, NYLOK
    NUT, NYLOK
  • 3
    4010794 REGULATOR AC/DC
    REGULATOR AC/DC
  • 4
    7555746 WASHER
    WASHER
  • 5
    4010730 REGULATOR RCTFR, 1/2WAVE, WITH CONN (M-10 ACE)
    REGULATOR RCTFR, 1/2WAVE, WITH CONN (M-10 ACE)
  • 6
    4010193 HOUSING CONNECTOR
    HOUSING CONNECTOR
  • 7
    4010192 SOCKET PACKARD
    SOCKET PACKARD
  • 8
    4020063 HOUSING, PACK
    HOUSING, PACK
  • 9
    4020153 HOUSING, 1 CIRCUIT
    HOUSING, 1 CIRCUIT
  • 10
    2461146 HARNESS MAIN, DIAG
    HARNESS MAIN, DIAG
  • 10
    2461149 HARNESS MAIN DIAG (M-10 ACE)
    HARNESS MAIN DIAG (M-10 ACE)
  • 11
    4020057 HOUSING
    HOUSING
  • 12
    7515199 SCREW
    SCREW
  • 13
    7080946 CABLE CHOKE (INCL. 15, 14)
    CABLE CHOKE (INCL. 15, 14)
  • 14
    5432944 NUT, CHOKE
    NUT, CHOKE
  • 15
    5432943 CHOKE LEVER REPAIR KIT (INCL. PIN)
    CHOKE LEVER REPAIR KIT (INCL. PIN)
  • 16
    7670088 CLIP, PLASTIC DART NYLON
    CLIP, PLASTIC DART NYLON
  • 17
    2201614 IGNITION SWITCH FUEL KIT
    IGNITION SWITCH FUEL KIT
  • 18
    7547035 NUT, IGNITION
    NUT, IGNITION
  • 19
    5410611 N/A, USE COMPONENTS (SEE NOTE)
    N/A, USE COMPONENTS (SEE NOTE)
  • 20
    4010638 RECEPTACLE POD MOUNT, 12 VOLT
    RECEPTACLE POD MOUNT, 12 VOLT
  • 21
    5434483-070 CONSOLENOIDE, SRP WITH ACC (BLACK)
    CONSOLENOIDE, SRP WITH ACC (BLACK)
  • 22
    7512050 SCREW, WITH WASHER
    SCREW, WITH WASHER
