CLUTCH - DRIVE для Polaris FRONTIER TOURING (S03NT7DS) - 2003 года выпуска

  • №
    Артикул
    Название
  • 1
    7512265 BOLT
    BOLT
  • 2
    7552801 WASHER SPRING LOCK
    WASHER SPRING LOCK
  • 3
    3576516 BEARING COVER
    BEARING COVER
  • 4
    7710417 RING, RETAINING, COVER
    RING, RETAINING, COVER
  • 5
    7041102 SPRING CLUTCH (YELLOW)
    SPRING CLUTCH (YELLOW)
  • 6
    5430945 WASHER
    WASHER
  • 7
    1321622 ROLLER AND BUSHING, ASSY.
    ROLLER AND BUSHING, ASSY.
  • 8
    5430445 BUTTON, GUIDE
    BUTTON, GUIDE
  • 9
    1321586 WT/BUSH. ASSY. 10-62
    WT/BUSH. ASSY. 10-62
  • 10
    7515105 PIN, WT. HARDENED
    PIN, WT. HARDENED
  • 11
    3576502 BEARING SLEEVE
    BEARING SLEEVE
  • 12
    5010188 INSERT, MOVEABLE
    INSERT, MOVEABLE
  • 13
    7541906 NUT FLEXLOC
    NUT FLEXLOC
  • 14
    5210754 SPACER (.050MM)
    SPACER (.050MM)
  • 14
    5210753 SPACER (.032MM)
    SPACER (.032MM)
  • 14
    5242981 SPACER (.025MM)
    SPACER (.025MM)
  • 14
    5210752 SPACER (.020MM)
    SPACER (.020MM)
  • 15
    5020425 NUT, JAM
    NUT, JAM
  • 16
    5133079 PIN ROLLER, 1" SBN
    PIN ROLLER, 1" SBN
  • 17
    2200387 SHIM, DRIVE CLUTCH KIT
    SHIM, DRIVE CLUTCH KIT
  • 18
    1321810 DRIVE CLUTCH, ASSY. BASIC 102 (INCL. ALL LESS 5, 9)
    DRIVE CLUTCH, ASSY. BASIC 102 (INCL. ALL LESS 5, 9)
  • 18
    2201169 WIDE ROLLER SPIDER REBUILD KIT (INCL. 6-8, 10, 16)
    WIDE ROLLER SPIDER REBUILD KIT (INCL. 6-8, 10, 16)
