SUSPENSION - FRONT для Polaris 440 PRO X (S03NX4CS) - 2003 года выпуска

  • №
    Артикул
    Название
  • 2
    7661637 RIVET, INTERLOCK Z
    RIVET, INTERLOCK Z
  • 3
    5245250 BRACKET RAD ROD STRAP (LOWER)
    BRACKET RAD ROD STRAP (LOWER)
  • 4
    1013733 WELD RAD ROD SUPPORT, REINFORCEMENT
    WELD RAD ROD SUPPORT, REINFORCEMENT
  • 5
    5132897 BUSHING
    BUSHING
  • 6
    5245307 PLATE (LOWER/INNER)
    PLATE (LOWER/INNER)
  • 7
    7517583 SCREW HEXAGON/CAP
    SCREW HEXAGON/CAP
  • 8
    7042187-385 SPRING COMP (SILVER)
    SPRING COMP (SILVER)
  • 9
    7517980 BOLT HEXAGON CAP, GR5-Y
    BOLT HEXAGON CAP, GR5-Y
  • 10
    7542703 NUT FLEXOC
    NUT FLEXOC
  • 11
    7515415 SCREW
    SCREW
  • 12
    5133320 SPACER
    SPACER
  • 13
    7542439 NUT, NYLOK
    NUT, NYLOK
  • 14
    7042180 SHOCK IFS, WALKER/EVANS
    SHOCK IFS, WALKER/EVANS
  • 15
    7515433 SCREW
    SCREW
  • 16
    7555832 WASHER
    WASHER
  • 17
    2874341 KIT STEERING ARM
    KIT STEERING ARM
  • 18
    7555797 WASHER FLAT
    WASHER FLAT
  • 19
    7547066 NUT 7/16-20, NYLOK, Y
    NUT 7/16-20, NYLOK, Y
  • 20
    7555820 WASHER FLAT
    WASHER FLAT
  • 21
    5133990 CUP TRAILING ARM MOUNT
    CUP TRAILING ARM MOUNT
  • 22
    7061094 BEARING SPHERICAL 7/16 NYLON
    BEARING SPHERICAL 7/16 NYLON
  • 23
    7710437 RING, RETAINING
    RING, RETAINING
  • 24
    7512099 SCREW
    SCREW
  • 25
    1821147-385 TRAILING ARM, ASSY (LEFT/CLOUD SILVER) (INCL. 22, 23)
    TRAILING ARM, ASSY (LEFT/CLOUD SILVER) (INCL. 22, 23)
  • 25
    1821148-385 TRAILING ARM, ASSY (RIGHT/CLOUD SILVER) (INCL. 22, 23)
    TRAILING ARM, ASSY (RIGHT/CLOUD SILVER) (INCL. 22, 23)
  • 26
    7061057 ROD END (RIGHT)
    ROD END (RIGHT)
  • 27
    3514376 BUSHING FLANGE
    BUSHING FLANGE
  • 28
    7080433 FITTING, LUBRICATION THREADED
    FITTING, LUBRICATION THREADED
  • 29
    7556207 BUSHING
    BUSHING
  • 30
    3514377 BUSHING FLANGE
    BUSHING FLANGE
  • 31
    6230248-067 SHAFT SPINDLE (BLACK)
    SHAFT SPINDLE (BLACK)
  • 32
    7080306 FITTING, LUBE. W/BALL CHECK
    FITTING, LUBE. W/BALL CHECK
  • 33
    5010158 BUSHING, PIVOT
    BUSHING, PIVOT
  • 34
    7542520 NUT, JAM
    NUT, JAM
  • 35
    5133686 TUBE SWEDGED, MACHINED (UPPER/REAR)
    TUBE SWEDGED, MACHINED (UPPER/REAR)
  • 36
    7547117 NUT (LEFT)
    NUT (LEFT)
  • 37
    7061107 ROD END (REAR/LEFT)
    ROD END (REAR/LEFT)
  • 38
    7555928 WASHER
    WASHER
  • 39
    7061108 ROD END (REAR/RIGHT)
    ROD END (REAR/RIGHT)
  • 40
    7517907 BOLT HEXAGON CAP GR5-Y
    BOLT HEXAGON CAP GR5-Y
  • 41
    7547065 NUT 1/2-20, NYLOK, Y
    NUT 1/2-20, NYLOK, Y
  • 42
    7061106 ROD END (REAR/RIGHT)
    ROD END (REAR/RIGHT)
  • 43
    7517906 BOLT HEXAGON CAP, GR5-Y
    BOLT HEXAGON CAP, GR5-Y
  • 44
    7542711 NUT JAM
    NUT JAM
  • 45
    5133685 TUBE SWEDGED, MACHINED (REAR/LOWER)
    TUBE SWEDGED, MACHINED (REAR/LOWER)
  • 46
    7547028 NUT, JAM (LEFT)
    NUT, JAM (LEFT)
  • 47
    7061105 ROD END (REAR/LEFT)
    ROD END (REAR/LEFT)
  • 48
    7542503 NUT, FLEXLOCK
    NUT, FLEXLOCK
  • 49
    7512656 BOLT
    BOLT
