SUSPENSION - FRONT SHOCK для Polaris 700 CLASSIC BUILT AFTER 1/1/01 (S02ND7CS) - 2002 года выпуска

  • №
    Артикул
    Название
  • 1
    1500443 BODY CAP ASSY.
    BODY CAP ASSY.
  • 2
    1500108 O-RING (.103W, 1.549ID)
    O-RING (.103W, 1.549ID)
  • 3
    1500187 PISTON, FLOATING
    PISTON, FLOATING
  • 4
    1500015 BUSHING, BACKUP
    BUSHING, BACKUP
  • 5
    1500017 PLATE, TOP OUT
    PLATE, TOP OUT
  • 6
    1500186 BEARING, ASSEMBLY
    BEARING, ASSEMBLY
  • 7
    1500247 SHAFT
    SHAFT
  • 8
    1500441 BUMPER (.498 ID X .883 TLG)
    BUMPER (.498 ID X .883 TLG)
  • 9
    1500164 EYELET, BASE
    EYELET, BASE
  • 10
    1500310 SLEEVE (.56X.81X1.2)
    SLEEVE (.56X.81X1.2)
  • 11
    1500266 U, CUP (4300 URETH, 036, 01, 006)
    U, CUP (4300 URETH, 036, 01, 006)
  • 12
    5433298 SEAL,WIPER URETHANE (FOX)
    SEAL,WIPER URETHANE (FOX)
  • 13
    1500021 O-RING INNER
    O-RING INNER
  • 14
    1500070 SCREW
    SCREW
  • 15
    1500071 BALL (FOX)
    BALL (FOX)
  • 16
    1500020 O-RING.(103W, 1.299ID)
    O-RING.(103W, 1.299ID)
  • 17
    1500002 DAMPER, PISTONRING, FOX)
    DAMPER, PISTONRING, FOX)
  • 18
    2200618 VALV.PISTON KIT (FOX SHOCK)
    VALV.PISTON KIT (FOX SHOCK)
  • 19
    1500016 NUT, LOCK
    NUT, LOCK
  • 20
    1500458 BODY
    BODY
  • 21
    1500003 O-RING, ENDCAP (FOX)
    O-RING, ENDCAP (FOX)
  • 22
    1500006 RING, PISTON, FLOATING (FOX)
    RING, PISTON, FLOATING (FOX)
  • 23
    1500022 O-RING, DRUM OUTER
    O-RING, DRUM OUTER
  • 24
    1500018 SCREW
    SCREW
  • 25
    1500444 BEARING
    BEARING
  • 26
    5432304 RING, SPRING PRELOAD, ADJ
    RING, SPRING PRELOAD, ADJ
  • 27
    1500309 BUSHING (.35ILG, .595TLG)
    BUSHING (.35ILG, .595TLG)
  • 27
    7042094 SHOCK, FRONT TRACK (M, 10)
    SHOCK, FRONT TRACK (M, 10)
