SUSPENSION - FRONT для Polaris 440 PRO X FAN COOLED (S02NX4FS) - 2002 года выпуска
-
№АртикулНазвание
-
17661637 RIVET, INTERLOCKRIVET, INTERLOCK
-
25245740-067 BRACKET, RAD ROD SUPPORT (BLACK)BRACKET, RAD ROD SUPPORT (BLACK)
-
35245250 BRACKET, RAD ROD STRAP (LOWER)BRACKET, RAD ROD STRAP (LOWER)
-
41013733 WELD, RAD ROD SUPPORTWELD, RAD ROD SUPPORT
-
55132897 BUSHING, RAD (UPPER)BUSHING, RAD (UPPER)
-
67517980 BOLTBOLT
-
77542703 NUT, FLEXNUT, FLEX
-
85245307 PLATE, RADIUS ROD (LOWER/INNER)PLATE, RADIUS ROD (LOWER/INNER)
-
97061077 ROD END, RAD (LEFT)ROD END, RAD (LEFT)
-
107547117 NUTNUT
-
115333984-216 TUBE, RADIUS ROD (UPPER/YELLOW)TUBE, RADIUS ROD (UPPER/YELLOW)
-
127542520 NUT JAMNUT JAM
-
137547066 NUT, NYLOCKNUT, NYLOCK
-
147515415 BOLTBOLT
-
151700066 SPACERSPACER
-
167517583 SCREWSCREW
-
177542439 NUT, NYLOCKNUT, NYLOCK
-
185020618 RETAINER, SPRING SLOTTEDRETAINER, SPRING SLOTTED
-
197042109 SHOCK, IFS COMPRESSIONSHOCK, IFS COMPRESSION
-
207042052-293 SPRING, COMP.SPRING, COMP.
-
217515433 BOLTBOLT
-
227555832 WASHERWASHER
-
232874341 STEERING ARM KITSTEERING ARM KIT
-
247555797 WASHERWASHER
-
257555820 WASHERWASHER
-
265132364 CUP, TRAILING ARM MNTCUP, TRAILING ARM MNT
-
277061094 BEARINGBEARING
-
287710437 RING, RETAININGRING, RETAINING
-
297512099 BOLTBOLT
-
301821147-216 TRAILING ARM ASSY. (LEFT/YELLOW) (INCL. 25, 26)TRAILING ARM ASSY. (LEFT/YELLOW) (INCL. 25, 26)
-
301821148-216 TRAILING ARM ASSY. (RIGHT/YELLOW) (INCL. 25, 26)TRAILING ARM ASSY. (RIGHT/YELLOW) (INCL. 25, 26)
-
317061057 ROD, END (RIGHT)ROD, END (RIGHT)
-
323514376 BUSHING, FLANGEBUSHING, FLANGE
-
337080433 ZERK, FITTING THREADEDZERK, FITTING THREADED
-
347556207 BUSHINGBUSHING
-
353514377 BUSHING, FLANGEBUSHING, FLANGE
-
365433234 BUSHING, TORSION BARBUSHING, TORSION BAR
-
377621452 RIVETRIVET
-
385246062-067 BAR, TORSION (BLACK)BAR, TORSION (BLACK)
-
395434481 SLIDE, TORSION BARSLIDE, TORSION BAR
-
406230248-067 SHAFT, SPINDLE (BLACK)SHAFT, SPINDLE (BLACK)
-
417080306 FITTING, LUBE W/BALL CHECKFITTING, LUBE W/BALL CHECK
-
425010158 BUSHING, PIVOTBUSHING, PIVOT
-
437061078 ROD END, RAD (RIGHT)ROD END, RAD (RIGHT)
-
447517907 BOLTBOLT
-
457547065 NUT, NYLOCKNUT, NYLOCK
-
467061080 ROD END W/RADIUS (RIGHT)ROD END W/RADIUS (RIGHT)
-
477517906 BOLTBOLT
-
487542711 NUT, JAMNUT, JAM
-
495333985-216 TUBE, RADIUS ROD (LOWER/YELLOW)TUBE, RADIUS ROD (LOWER/YELLOW)
-
507547028 NUT, JAM (LEFT)NUT, JAM (LEFT)
-
517061079 ROD END, RAD (LEFT)ROD END, RAD (LEFT)
-
527542503 NUT, LOCKNUT, LOCK
-
537512656 BOLTBOLT
