STEERING ASSEMBLY для Polaris 500 CLASSIC TOURING (S01ST4BS) - 2001 года выпуска

  • №
    Артикул
    Название
  • 1
    7621340 RIVET
    RIVET
  • 2
    7512404 BOLT
    BOLT
  • 3
    7080433 ZERK, FITTING, THREADED
    ZERK, FITTING, THREADED
  • 4
    4020139 CLIP, PLASTIC
    CLIP, PLASTIC
  • 5
    5010463 BUSHING
    BUSHING
  • 6
    7555721 WASHER
    WASHER
  • 7
    7542703 NUT FLEX
    NUT FLEX
  • 8
    7661203 PIN COTTER
    PIN COTTER
  • 9
    7060164 ROD END, (LEFT).
    ROD END, (LEFT).
  • 9
    7060165 ROD END, (RIGHT).
    ROD END, (RIGHT).
  • 10
    7542403 NUT LOCK
    NUT LOCK
  • 11
    7542424 NUT
    NUT
  • 11
    7542401 NUT HEX
    NUT HEX
  • 12
    5332712 ROD, DRAG LINK
    ROD, DRAG LINK
  • 13
    7080272 STRAP, (BLACK)
    STRAP, (BLACK)
  • 15
    7080804 CABLE TIE, RELEASABLE, (5 1/2'')
    CABLE TIE, RELEASABLE, (5 1/2'')
  • 16
    1012887-067 STEERING HOOP, SHORT, (BLACK)
    STEERING HOOP, SHORT, (BLACK)
  • 17
    7542303 NUT FLEX, LOC
    NUT FLEX, LOC
  • 18
    7517428 BOLT
    BOLT
  • 19
    7661637 RIVET, INTERLOCK, Z
    RIVET, INTERLOCK, Z
  • 20
    7542103 NUT, LOCK
    NUT, LOCK
  • 21
    7512275 BOLT, CARRIAGE
    BOLT, CARRIAGE
  • 22
    5411122 BOOT, TIEROD, (LEFT), XTRA
    BOOT, TIEROD, (LEFT), XTRA
  • 22
    5411123 BOOT, TIEROD, (RIGHT), XTRA
    BOOT, TIEROD, (RIGHT), XTRA
  • 23
    7061005 ROD END, (LEFT), (3/8 HI, ANGLE PRO)
    ROD END, (LEFT), (3/8 HI, ANGLE PRO)
  • 23
    7060174 ROD, END, (RIGHT), (3/8, HI, ANGLE)
    ROD, END, (RIGHT), (3/8, HI, ANGLE)
  • 24
    5211454-067 PLATE, BOOTSEAT, (BLACK)
    PLATE, BOOTSEAT, (BLACK)
  • 25
    5020859-067 ROD, TIE, (BLACK)
    ROD, TIE, (BLACK)
  • 26
    5630563 BLOCK, STRG, (CAST)
    BLOCK, STRG, (CAST)
  • 27
    7512682 BOLT
    BOLT
  • 28
    7555735 WASHER, WAVE
    WASHER, WAVE
  • 29
    3563907 BUSHING
    BUSHING
  • 30
    5211453-067 PLATE, (RIGHT), BOOTSEAL, (BLACK)
    PLATE, (RIGHT), BOOTSEAL, (BLACK)
  • 31
    1822286 STRG.ASSY., CTR. (INCL. 3, 29)
    STRG.ASSY., CTR. (INCL. 3, 29)
