SUSPENSION - FOX SHOCK - IFS LEFT AND RIGHT HAND- FRONT для Polaris 600 XC SP EDGE (S00NP6ES) - 2000 года выпуска`
-
№АртикулНазвание
-
297041926 SHOCK, GAS, IFP, 11. 02X16. 25SHOCK, GAS, IFP, 11. 02X16. 25
-
292200618 VALV. PISTON KIT (FOX SHOCK)VALV. PISTON KIT (FOX SHOCK)
-
11500137 BUSHING, EYELETBUSHING, EYELET
-
25020613 BUSHING (1. 16 IN. )BUSHING (1. 16 IN. )
-
35432304 RING, SPRING PRELOAD, ADJUSTRING, SPRING PRELOAD, ADJUST
-
41500186 BEARING-ASSEMBLYBEARING-ASSEMBLY
-
41500020 O-RINGO-RING
-
41500021 O-RING (INNER)O-RING (INNER)
-
41500268 SEAL, WIPER URETHANESEAL, WIPER URETHANE
-
41500266 U-CUP-4300 URETH, 036-01-006U-CUP-4300 URETH, 036-01-006
-
41500070 SCREWSCREW
-
41500071 BALLBALL
-
55410855 BUMPER, JOUNCEBUMPER, JOUNCE
-
61500138 SLEEVE, STEELSLEEVE, STEEL
-
75431355 SPACERSPACER
-
81500017 PLATE (TOP/OUTER)PLATE (TOP/OUTER)
-
91500002 DAMPER, PISTONRINGDAMPER, PISTONRING
-
101500015 BUSHING, BACKUPBUSHING, BACKUP
-
111500016 NUT, LOCKNUT, LOCK
-
121500108 O-RING, . 103W-1. 549IDO-RING, . 103W-1. 549ID
-
131500072 VALVE ASSY., AIRVALVE ASSY., AIR
-
131500014 VALVE ASSY., AIRVALVE ASSY., AIR
-
131500019 SCREWSCREW
-
131500023 O-RING (OUTER)O-RING (OUTER)
-
141500316 CAP, ASSY., BODYCAP, ASSY., BODY
-
151500018 SCREWSCREW
-
151500022 O-RING, DRUM (OUTER)O-RING, DRUM (OUTER)
-
161500003 O-RING, ENDCAPO-RING, ENDCAP
-
171500006 RING, PISTON, FLOATINGRING, PISTON, FLOATING
-
181500187 PISTON-FLOATINGPISTON-FLOATING
-
191500289 BODY, 1. 46X8. 18 TLG 204-04-004BODY, 1. 46X8. 18 TLG 204-04-004
-
201500205 SHAFT-0. 498 ODX8. 000 TRAILINGSHAFT-0. 498 ODX8. 000 TRAILING
-
211500317 EYELET, 1. 5 BASE, 2. 01EYELET, 1. 5 BASE, 2. 01
