CARBURETOR ASSEMBLY для Polaris 500 CLASSIC (S00SD4BS) - 2000 года выпуска

  • №
    Артикул
    Название
  • 1
    3130184 TOP ASSY. (INCL. GASKET)
    TOP ASSY. (INCL. GASKET)
  • 2
    3130444 SPRING, THROTTLE
    SPRING, THROTTLE
  • 3
    3130054 PLATE, THROTTLE
    PLATE, THROTTLE
  • 4
    3130508 E-RING
    E-RING
  • 5
    3130378 NEEDLE, JET (6F9-3)
    NEEDLE, JET (6F9-3)
  • 6
    3130454 VALVE, THROTTLE (2.5)
    VALVE, THROTTLE (2.5)
  • 7
    3130733 NEEDLE JET #247
    NEEDLE JET #247
  • 8
    3130479 CAP
    CAP
  • 9
    3130047 WASHER
    WASHER
  • 10
    3130942 VALVE ASSY., NEEDLE (1.5)
    VALVE ASSY., NEEDLE (1.5)
  • 11
    3130361 PIN, FLOAT
    PIN, FLOAT
  • 12
    3130048 ARM, FLOAT
    ARM, FLOAT
  • 13
    3130237 CAP
    CAP
  • 14
    3130021 FLOAT ASSY.
    FLOAT ASSY.
  • 15
    3130941 CARBURETOR ASSY. (INCL. 2-17, 21-33)
    CARBURETOR ASSY. (INCL. 2-17, 21-33)
  • 16
    3130239 O-RING
    O-RING
  • 17
    5020476 FITTING, SEDIMENT
    FITTING, SEDIMENT
  • 18
    5431893 PLUG, TRAP
    PLUG, TRAP
  • 19
    7080003 CLAMP, HOSE
    CLAMP, HOSE
  • 20
    8350017-08 SPACER (OPT)
    SPACER (OPT)
  • 21
    3130056 SCREW
    SCREW
  • 22
    3130236 GASKET, FLOAT CHAMBER
    GASKET, FLOAT CHAMBER
  • 23
    3130138 JET, MAIN #350
    JET, MAIN #350
  • 24
    3130232 RING, CARB
    RING, CARB
  • 25
    3130243 PLATE
    PLATE
  • 26
    3130068 JET, PILOT #45
    JET, PILOT #45
  • 27
    3130009 SCREW, THROTTLE STOP
    SCREW, THROTTLE STOP
  • 28
    3130010 SPRING, THROTTLE ADJUST
    SPRING, THROTTLE ADJUST
  • 29
    3130011 SCREW, AIR
    SCREW, AIR
  • 30
    3130012 SPRING, AIR ADJUST
    SPRING, AIR ADJUST
  • 31
    3130328 PLUNGER ASSY., STARTER
    PLUNGER ASSY., STARTER
  • 32
    3130006 SPRING, PLUNGER
    SPRING, PLUNGER
  • 33
    3130199 HOLDER, GUIDE
    HOLDER, GUIDE
