SUSPENSION - FOX SHOCK - IFS LEFT AND RIGHT HAND- FRONT для Polaris 440 XC SP (S00NX4CS) - 2000 года выпуска`
-
№АртикулНазвание
-
11500092 REDUCER (FOX) (SP)REDUCER (FOX) (SP)
-
21500093 O-RING (FOX) (SP)O-RING (FOX) (SP)
-
37710446 RING, SNAP (FOX SP)RING, SNAP (FOX SP)
-
43513506 BEARING, SPHERICALBEARING, SPHERICAL
-
55432304 RING, SPRING PRELOAD, ADJUSTRING, SPRING PRELOAD, ADJUST
-
61500020 O-RING (.103W, 1.299ID)O-RING (.103W, 1.299ID)
-
61500021 O-RING (INNER)O-RING (INNER)
-
61500070 SCREWSCREW
-
61500071 BALL (FOX)BALL (FOX)
-
61500186 BEARING, ASSEMBLYBEARING, ASSEMBLY
-
61500266 U-CUP,U-CUP,
-
61500268 SEAL, WIPER URETHANESEAL, WIPER URETHANE
-
75410855 BUMPER, JOUNCEBUMPER, JOUNCE
-
81500137 BUSHING, EYELETBUSHING, EYELET
-
95020808 SLEEVE, SHAFT ENDSLEEVE, SHAFT END
-
105431355 SPACERSPACER
-
111500017 PLATE (TOP) (OUTER)PLATE (TOP) (OUTER)
-
121500002 DAMPER, PISTONRING, FOXDAMPER, PISTONRING, FOX
-
131500015 BUSHING, BACKUPBUSHING, BACKUP
-
141500016 NUT, LOCKNUT, LOCK
-
151500108 O-RING (.103W, 1.549ID)O-RING (.103W, 1.549ID)
-
161500014 VALVE ASSY., AIRVALVE ASSY., AIR
-
161500019 SCREWSCREW
-
161500023 O-RING (OUTER)O-RING (OUTER)
-
161500072 VALVE, AIR ASSY.VALVE, AIR ASSY.
-
171500316 CAP, ASSY., BODYCAP, ASSY., BODY
-
181500018 SCREWSCREW
-
181500022 O-RING, DRUM (OUTER)O-RING, DRUM (OUTER)
-
191500003 O-RING, ENDCAP, FOXO-RING, ENDCAP, FOX
-
201500006 RING, PISTON, FLOATING, FOXRING, PISTON, FLOATING, FOX
-
211500187 PISTON, FLOATINGPISTON, FLOATING
-
221500320 BODY, 8.8 TLG, 5.5 THDBODY, 8.8 TLG, 5.5 THD
-
231500272 SHAFT (.498 X 8.7)SHAFT (.498 X 8.7)
-
241500317 EYELET, 1.5 BASE, 2.01EYELET, 1.5 BASE, 2.01
-
247041838 SHOCK, GAS (IFS) (IFP)SHOCK, GAS (IFS) (IFP)
-
242200618 VALVE PISTON, KIT (FOX SHOCK)VALVE PISTON, KIT (FOX SHOCK)
