CONTROL PANEL для Polaris SCRAMBLER 2X4 (A00BA38CA) - 2000 года выпуска
-
№АртикулНазвание
-
14010140 INDICATOR, "LOW OIL"INDICATOR, "LOW OIL"
-
24040054 INDICATOR, "NEUT./REV."INDICATOR, "NEUT./REV."
-
34040053 INDICATOR, "HOT TEMPERATURE"INDICATOR, "HOT TEMPERATURE"
-
45433534 KEY COVER, KEYSWITCHKEY COVER, KEYSWITCH
-
54110264 SWITCH, IGNITION (INCL. KEY)SWITCH, IGNITION (INCL. KEY)
-
54010278 KEY BLANK (6700 & 6800 SERIES)KEY BLANK (6700 & 6800 SERIES)
-
54010321 KEY BLANK (2700 & 2800 SERIES)KEY BLANK (2700 & 2800 SERIES)
-
65433733 NUT, IGN SWITCHNUT, IGN SWITCH
-
75431976 PANEL, CONTROL (OUTER)PANEL, CONTROL (OUTER)
-
87512026 SCREWSCREW
-
92460664 HARNESS, CON PANEL (SCR.)HARNESS, CON PANEL (SCR.)
-
105431975 PANEL, CONTROL (INNER)PANEL, CONTROL (INNER)
-
117080371 CABLE, CHOKECABLE, CHOKE
