GIMBAL HOUSING AND GIMBAL RING ASSEMBLY для Mercruiser - II 1964-1967 1602186 THRU 2278488

№

Артикул

Название
1

37267A1 GIMBAL HOUSING ASSEMBLY
SERIAL 01602186-01732379

GIMBAL HOUSING ASSEMBLY
SERIAL 01602186-01732379
1

37267A1 GIMBAL HOUSING ASSEMBLY
SERIAL 01732380-02278488

GIMBAL HOUSING ASSEMBLY
SERIAL 01732380-02278488
2

26-32911 OIL SEAL, GIMBAL HOUSING

OIL SEAL, GIMBAL HOUSING
3

31-31559T BEARING, ROLLER-GIMBAL HOUSING

BEARING, ROLLER-GIMBAL HOUSING
4

22-74036 FITTING, GREASE-GIMBAL HOUSING

FITTING, GREASE-GIMBAL HOUSING
5

19-77633Q LUBRICAP, GIMBAL HOUSING GREASE FITTING

LUBRICAP, GIMBAL HOUSING GREASE FITTING
6

15-35244A1 SHIM, GIMBAL HOUSING BALL BEARING (.002-3-4-5-6-7-8-10)

SHIM, GIMBAL HOUSING BALL BEARING (.002-3-4-5-6-7-8-10)
7

23-35130 ADAPTOR, BALL BEARING

ADAPTOR, BALL BEARING
8

30-36418 CARRIER, BEARING-GIMBAL HOUSING BALL BEARING
SERIAL 01602186-01732379

CARRIER, BEARING-GIMBAL HOUSING BALL BEARING
SERIAL 01602186-01732379
9

30-36418 BEARING, BALL-GIMBAL HOUSING
SERIAL 01602186-01732379

BEARING, BALL-GIMBAL HOUSING
SERIAL 01602186-01732379
10

53-35129 RING, RETAINING-BALL BEARING (SMALL)
SERIAL 01602186-01732379

RING, RETAINING-BALL BEARING (SMALL)
SERIAL 01602186-01732379
11

53-35128 RING, RETAINING-BALL BEARING (LARGE)
SERIAL 01602186-01732379

RING, RETAINING-BALL BEARING (LARGE)
SERIAL 01602186-01732379
12

26-36146 OIL SEAL, GIMBAL HOUSING ADAPTOR
SERIAL 01602186-01732379

OIL SEAL, GIMBAL HOUSING ADAPTOR
SERIAL 01602186-01732379
13

36144 ADAPTOR, GIMBAL HOUSING
SERIAL 01602186-01732379

ADAPTOR, GIMBAL HOUSING
SERIAL 01602186-01732379
14

25-36145 "O" RING, GIMMBAL HOUSING ADAPTOR (LARGE)
SERIAL 01602186-01732379

"O" RING, GIMMBAL HOUSING ADAPTOR (LARGE)
SERIAL 01602186-01732379
9

30-36418 BEARING, BALL-GIMBAL HOUSING
SERIAL 01732380-02278488

BEARING, BALL-GIMBAL HOUSING
SERIAL 01732380-02278488
12

26-88416 GREASE SEAL, GIMBAL HOUSING ADAPTOR
SERIAL 01732380-02278488

GREASE SEAL, GIMBAL HOUSING ADAPTOR
SERIAL 01732380-02278488
13

37250T ADAPTOR, GIMBAL HOUSING
SERIAL 01732380-02278488

ADAPTOR, GIMBAL HOUSING
SERIAL 01732380-02278488
14

25-31305 "O" RING, GIMBAL HOUSING ADAPTOR (LARGE)
SERIAL 01732380-02278488

"O" RING, GIMBAL HOUSING ADAPTOR (LARGE)
SERIAL 01732380-02278488
15

25-33145 "O" RING, GIMBAR HOUSING ADAPTOR (SMALL)

"O" RING, GIMBAR HOUSING ADAPTOR (SMALL)
16

31635 SEAL, RUBBER-GIMBAL HOUSING TO OUTER TRANSOM PLATE

SEAL, RUBBER-GIMBAL HOUSING TO OUTER TRANSOM PLATE
17

12-31653 WASHER, SEPARATING-GIMBAL HOUSING TO OUTER TRANSOM PLATE

WASHER, SEPARATING-GIMBAL HOUSING TO OUTER TRANSOM PLATE
18

19-31843 WELCH PLUG, UPPER PIVOT BOLT COVER-GIMBAL HOUSING

WELCH PLUG, UPPER PIVOT BOLT COVER-GIMBAL HOUSING
19

10-31628 BOLT, PIVOT-GIMBAL RING (UPPER)

BOLT, PIVOT-GIMBAL RING (UPPER)
20

12-36362 WASHER, UPPER PIVOT BOLT

WASHER, UPPER PIVOT BOLT
21

11-22339 NUT, UPPER PIVOT BOLT

NUT, UPPER PIVOT BOLT
22

17-31627 PIN, UPPER PIVOT BOLT LOCKING

PIN, UPPER PIVOT BOLT LOCKING
23

54-24836 CLIP, TILT STOP SWITCH LEADS TO GIMBAL HOUSING

CLIP, TILT STOP SWITCH LEADS TO GIMBAL HOUSING
24

10-31903 SCREW, TILT STOP SWITCH LEADS CLIP TO GIMBAL HOUSING (3/8")

SCREW, TILT STOP SWITCH LEADS CLIP TO GIMBAL HOUSING (3/8")
25

8M0084613 "D" WASHER, TILT STOP SWITCH LEADS CLIP SCREW

"D" WASHER, TILT STOP SWITCH LEADS CLIP SCREW
26

10-31877 SCREW, GIMBAL HOUSING TO STEERING LEVER HOUSING (1 1/2")

SCREW, GIMBAL HOUSING TO STEERING LEVER HOUSING (1 1/2")
27

12-20959 WASHER, GIMBAL HOUSING SCREW

WASHER, GIMBAL HOUSING SCREW
28

54-815504372 CLAMP, UNIVERSAL JOINT BELLOWS TO GIMBAL HOUSING (SMALL)

CLAMP, UNIVERSAL JOINT BELLOWS TO GIMBAL HOUSING (SMALL)
29

34088A1 BELLOWS, UNIVERSAL JOINT COVERING

BELLOWS, UNIVERSAL JOINT COVERING
30

54-815504396 CLAMP, UNIVERSAL JOINT BELLOWS TO DRIVE SHAFT HOUSING (LARGE)

CLAMP, UNIVERSAL JOINT BELLOWS TO DRIVE SHAFT HOUSING (LARGE)
31

17-31634 PIN, SWIVEL-GIMBAL HOUSING TO GIMBAL RING (LOWER)

PIN, SWIVEL-GIMBAL HOUSING TO GIMBAL RING (LOWER)
32

18-36377 COTTER PIN, RETAINING-LOWER SWIVEL PIN

COTTER PIN, RETAINING-LOWER SWIVEL PIN
33

54-815504320 CLAMP, SHIFT ACTUATING CABLE BELLOWS TO GIMBAL HOUSING

CLAMP, SHIFT ACTUATING CABLE BELLOWS TO GIMBAL HOUSING
34

74639A2 BELLOWS, SHIFT ACTUATING CABLE COVER

BELLOWS, SHIFT ACTUATING CABLE COVER
35

54-20386 CLAMP, SHIFT ACTUATING CABLE BELLOWS TO SHIFT ACTUATING CABL

CLAMP, SHIFT ACTUATING CABLE BELLOWS TO SHIFT ACTUATING CABL
36

17-35997 PIN, TILT ADJUSTMENT-GIMBAL RING

PIN, TILT ADJUSTMENT-GIMBAL RING
37

11-82671013 NUT, TILT ADJUSTMENT PIN

NUT, TILT ADJUSTMENT PIN
38

49223A1 GIMBAL RING ASSEMBLY
SERIAL 01602186-01732325

GIMBAL RING ASSEMBLY
SERIAL 01602186-01732325
38

38779A1 GIMBAL RING ASSEMBLY
SERIAL 01732326-01922479

GIMBAL RING ASSEMBLY
SERIAL 01732326-01922479
38

38779A1 GIMBAL RING ASSEMBLY
SERIAL 01922480-02278488

GIMBAL RING ASSEMBLY
SERIAL 01922480-02278488
39

26-32911 OIL SEAL, GIMBAL RING

OIL SEAL, GIMBAL RING
40

31-31559T BEARING, ROLLER-GIMBAL RING

BEARING, ROLLER-GIMBAL RING
41

22-69059 FITTING, GREASE-GIMBAL RING

FITTING, GREASE-GIMBAL RING
42

19-77633Q LUBRICAP, GIMBAL RING GREASE FITTING

LUBRICAP, GIMBAL RING GREASE FITTING
43

12-31581 WASHER, GIMBAL RING TO GIMBAL HOUSING

WASHER, GIMBAL RING TO GIMBAL HOUSING
44

17-35601 PIN, HINGE-GIMBAL RING TO DRIVE SHAFT HOUSING

PIN, HINGE-GIMBAL RING TO DRIVE SHAFT HOUSING
45

18-34212 COTTER PIN, HINGE PIN RETAINING-GIMBAL RING

COTTER PIN, HINGE PIN RETAINING-GIMBAL RING
46

12-31633 WASHER, GIMBAL RING HINGE PIN
SERIAL 01602186-01778953

WASHER, GIMBAL RING HINGE PIN
SERIAL 01602186-01778953
46

12-38334 WASHER, SYNTHANE-GIMBAL RING HINGE PIN
SERIAL 01778954-02278488

WASHER, SYNTHANE-GIMBAL RING HINGE PIN
SERIAL 01778954-02278488
47

32676A1 TILT STOP SWITCH ASSEMBLY, GIMBAL RING

TILT STOP SWITCH ASSEMBLY, GIMBAL RING
48

10-98253 SCREW, TILT STIP SWITCH COVER TO GIMBAL HOUSING (1/2")

SCREW, TILT STIP SWITCH COVER TO GIMBAL HOUSING (1/2")
49

23-31902 SPACER, TILT STOP SWITCH TO RETAINING PLATE

SPACER, TILT STOP SWITCH TO RETAINING PLATE
50

31899 PLATE, RETAINING-TILT STOP SWITCH TO GIMBAL RING

PLATE, RETAINING-TILT STOP SWITCH TO GIMBAL RING
51

10-31903 SCREW, RETAINING PLATE TO GIMBAL RING (3/8")

SCREW, RETAINING PLATE TO GIMBAL RING (3/8")
52

49343 LEVER, TILT STOP SWITCH ACUTATING-GIMBAL RING

LEVER, TILT STOP SWITCH ACUTATING-GIMBAL RING
53

10-31903 SCREW, TILT STIP SWITCH ACTUATING LEVER TO GIMBAL RING (3/8")

SCREW, TILT STIP SWITCH ACTUATING LEVER TO GIMBAL RING (3/8")
