DRIVE SHAFT HOUSING ASSEMBLY AND GEAR ASSEMBLY для Mercruiser - II 1964-1967 1602186 THRU 2278488

  • №
    Артикул
    Название
  • 1
    1544-2008A9 DRIVE SHAFT HOUSING ASSEMBLY
    SEE B14 FOR BREAKDOWN SERIAL 01602186-01732325
    DRIVE SHAFT HOUSING ASSEMBLY
    SEE B14 FOR BREAKDOWN SERIAL 01602186-01732325
  • 1
    1544-2549A11 DRIVE SHAFT HOUSING ASSEMBLY
    SEE B14 FOR BREAKDOWN SERIAL 01732326-01778953
    DRIVE SHAFT HOUSING ASSEMBLY
    SEE B14 FOR BREAKDOWN SERIAL 01732326-01778953
  • 1
    1544-2549A11 DRIVE SHAFT HOUSING ASSEMBLY
    SEE B14 FOR BREAKDOWN SERIAL 01778954-01941218
    DRIVE SHAFT HOUSING ASSEMBLY
    SEE B14 FOR BREAKDOWN SERIAL 01778954-01941218
  • 1
    1544-2549A11 DRIVE SHAFT HOUSING ASSEMBLY
    SEE B14 FOR BREAKDOWN SERIAL 01941219-02278488
    DRIVE SHAFT HOUSING ASSEMBLY
    SEE B14 FOR BREAKDOWN SERIAL 01941219-02278488
  • 2
    19-29850 PLUG, TRIM TAB HOLE-DRIVE SHAFT HOUSING
    PLUG, TRIM TAB HOLE-DRIVE SHAFT HOUSING
  • 3
    27-32277 GASKET, DRIVE SHAFT HOUSING TO GEAR HOUSING
    GASKET, DRIVE SHAFT HOUSING TO GEAR HOUSING
  • 4
    32-35127 TUBE, OIL-DRIVE SHAFT HOUSING
    TUBE, OIL-DRIVE SHAFT HOUSING
  • 5
    35231A1 COVER ASSEMBLY, SHIFT FORK
    COVER ASSEMBLY, SHIFT FORK
  • 6
    26183A5 EMBLEM ASSEMBLY, SHIFT FORK COVER
    EMBLEM ASSEMBLY, SHIFT FORK COVER
  • 7
    22-320181 PLUG, OIL FILLER-SHIFT FORK COVER
    PLUG, OIL FILLER-SHIFT FORK COVER
  • 8
    25-35126 RING, OIL FILLER PLUG
    RING, OIL FILLER PLUG
  • 9
    27-32366 GASKET, SHIFT FORK COVER
    GASKET, SHIFT FORK COVER
  • 10
    10-31716 SCREW, SHIFT FORK COVER TO DRIVE SHAFT HOUSING (5/8")
    SCREW, SHIFT FORK COVER TO DRIVE SHAFT HOUSING (5/8")
  • 11
    22-73379 PLUG, PIPE-OIL CHANNEL-DRIVE SHAFT HOUSING
    PLUG, PIPE-OIL CHANNEL-DRIVE SHAFT HOUSING
  • 12
    25-32068 "O" RING, TOP COVER SEALING
    "O" RING, TOP COVER SEALING
  • 13
    15-32363A1 SHIM, TOP COVER TO DRIVE SHAFT HOUSING (.002-3-5-10)
    SHIM, TOP COVER TO DRIVE SHAFT HOUSING (.002-3-5-10)
  • 14
    32367 COVER, TOP-DRIVE SHAFT HOUSING
    SEE BLOCK I ON C1 SERIAL 01602186-01732445
    COVER, TOP-DRIVE SHAFT HOUSING
    SEE BLOCK I ON C1 SERIAL 01602186-01732445
  • 15
    52-35176 CLUTCH, SLIDING-SHIFT FORK
    SEE BLOCK I ON C1 SERIAL 01602186-01732445
    CLUTCH, SLIDING-SHIFT FORK
    SEE BLOCK I ON C1 SERIAL 01602186-01732445
  • 16&17
    43-32261 GEAR, UPPER AND LOWER SEE BLOCK I ON C1
    SEE BLOCK I ON C1 SERIAL 01602186-01732445
    GEAR, UPPER AND LOWER SEE BLOCK I ON C1
    SEE BLOCK I ON C1 SERIAL 01602186-01732445
  • 18
    43-39377A3 GEAR, PINION-UNIVERSAL JOINT
    SEE BLOCK I ON C1 SERIAL 01602186-01732445
    GEAR, PINION-UNIVERSAL JOINT
    SEE BLOCK I ON C1 SERIAL 01602186-01732445
  • 14
    32367 COVER, TOP-DRIVE SHAFT HOUSING
    SEE BLOCK II ON C1 SERIAL 01732445-01922465
    COVER, TOP-DRIVE SHAFT HOUSING
    SEE BLOCK II ON C1 SERIAL 01732445-01922465
  • 15
    52-37239 CLUTCH, SLIDING-SHIFT FORK SEE BLOCK II ON C1
    SEE BLOCK II ON C1 SERIAL 01732445-01922465
    CLUTCH, SLIDING-SHIFT FORK SEE BLOCK II ON C1
    SEE BLOCK II ON C1 SERIAL 01732445-01922465
  • 16 & 1
    43-39377A3 GEAR ASSEMBLY, COMPLETE (INCLUDES FORWARD AND PINION GEAR)
    SEE BLOCK II ON C1 SERIAL 01732445-01922465
    GEAR ASSEMBLY, COMPLETE (INCLUDES FORWARD AND PINION GEAR)
    SEE BLOCK II ON C1 SERIAL 01732445-01922465
  • 17
    43-37238 GEAR, REVERSE
    SEE BLOCK II ON C1 SERIAL 01732445-01922465
    GEAR, REVERSE
    SEE BLOCK II ON C1 SERIAL 01732445-01922465
  • 14
    32367 COVER, TOP-DRIVE SHAFT HOUSING
    SEE BLOCK III ON C1 SERIAL 01922466-02278488
    COVER, TOP-DRIVE SHAFT HOUSING
    SEE BLOCK III ON C1 SERIAL 01922466-02278488
  • 15
    52-39322 CLUTCH, SLIDING-SHIFT FORK SEE BLOCK III ON C1
    SEE BLOCK III ON C1 SERIAL 01922466-02278488
    CLUTCH, SLIDING-SHIFT FORK SEE BLOCK III ON C1
    SEE BLOCK III ON C1 SERIAL 01922466-02278488
  • 16 & 1
    43-39377A2 GEAR ASSEMBLY, COMPLETE (INCLUDES FORWARD AND PINION GEAR)
    SEE BLOCK III ON C1 SERIAL 01922466-02278488
    GEAR ASSEMBLY, COMPLETE (INCLUDES FORWARD AND PINION GEAR)
    SEE BLOCK III ON C1 SERIAL 01922466-02278488
  • 17
    43-39321 GEGAR, REVERSE
    SEE BLOCK III ON C1 SERIAL 01922466-02278488
    GEGAR, REVERSE
    SEE BLOCK III ON C1 SERIAL 01922466-02278488
  • 19
    10-31985 SCREW, TOP COVER TO DRIVE SHAFT HOUSING (1 1/4")
    SCREW, TOP COVER TO DRIVE SHAFT HOUSING (1 1/4")
  • 20
    15-846353A1 SHIM, WASHER TO DRIVE SHAFT HOUSING (.002-3-5-10-25)
    SHIM, WASHER TO DRIVE SHAFT HOUSING (.002-3-5-10-25)
  • 21
    12-32161 WASHER, UPPER GEAR TAPERED ROLLER BEARING
    WASHER, UPPER GEAR TAPERED ROLLER BEARING
  • 22
    31-30894A4 TAPERED ROLLER BEARING ASSEMBLY, UPPER GEAR
    TAPERED ROLLER BEARING ASSEMBLY, UPPER GEAR
  • 23
    14-32054 TAB WASHER, TAPERED ROLLER BEARIG TO UPPER GEAR NUT
    TAB WASHER, TAPERED ROLLER BEARIG TO UPPER GEAR NUT
  • 24
    11-32060 NUT, TAPERED ROLLER BEARING TO UPPER GEAR
    NUT, TAPERED ROLLER BEARING TO UPPER GEAR
  • 25
    32087 RETAINER, LOWER GEAR TAPERED ROLLER BEARING CUP
    RETAINER, LOWER GEAR TAPERED ROLLER BEARING CUP
  • 26
    10-36375 SCREW, SET-TAPERED ROLLER BEARING CUP RETAINER
    SCREW, SET-TAPERED ROLLER BEARING CUP RETAINER
  • 27
    11-26484 NUT, JAM-TAPERED ROLLER BEARING CUP RETAINER SET SCREW
    NUT, JAM-TAPERED ROLLER BEARING CUP RETAINER SET SCREW
  • 28
    31-30894A4 TAPERED ROLLER BEARING ASSEMBLY, LOWER GEAR
    TAPERED ROLLER BEARING ASSEMBLY, LOWER GEAR
  • 29
    15-32057A1 SHIM, BEARING CUP TO DRIVE SHAFT HOUSING (.002-3-5-10-25)
    SHIM, BEARING CUP TO DRIVE SHAFT HOUSING (.002-3-5-10-25)
  • 30
    14-32054 TAB WASHER, TAPERED ROLLER BEARING TO LOWER GEAR NUT
    TAB WASHER, TAPERED ROLLER BEARING TO LOWER GEAR NUT
  • 31
    11-32060 NUT, TAPERED ROLLER BEARING TO LOWER GEAR
    NUT, TAPERED ROLLER BEARING TO LOWER GEAR
  • 32
    36013A1 UNIVERSAL JOINT ASSEMBLY, PINION GEAR
    UNIVERSAL JOINT ASSEMBLY, PINION GEAR
  • 33
    75832T1 CROSS AND BEARING ASSEMBLY, UNIVERSAL JOINT
    CROSS AND BEARING ASSEMBLY, UNIVERSAL JOINT
  • 34
    39496 YOKE, UNIVERSAL JOINT (COUPLING END)
    YOKE, UNIVERSAL JOINT (COUPLING END)
  • --
    39495 YOKE, UNIVERSAL JOINT (GEAR END)
    YOKE, UNIVERSAL JOINT (GEAR END)
  • --
    393831 SOCKET, CENTER-UNIVERSAL JOINT
    SOCKET, CENTER-UNIVERSAL JOINT
  • 35
    31576 RETAINER, PINION GEAR ROLLER BEARING
    RETAINER, PINION GEAR ROLLER BEARING
  • 36
    10-32132 SCREW, RETAINER TO DRIVE SHAFT HOUSING (1 3/4")
    SCREW, RETAINER TO DRIVE SHAFT HOUSING (1 3/4")
  • 37
    14-43589 TAB WASHER, RETAINER SCREW
    TAB WASHER, RETAINER SCREW
  • 38
    15-32062A1 SHIM, RETAINER TO DRIVE SHAFT HOUSING (.002-3-5-10-25)
    SHIM, RETAINER TO DRIVE SHAFT HOUSING (.002-3-5-10-25)
  • 39
    25-32069 "O" RING, ROLLER BEARING RETAINER
    "O" RING, ROLLER BEARING RETAINER
  • 40
    26-823894 OIL SEAL, ROLLER BEARING RETAINER
    OIL SEAL, ROLLER BEARING RETAINER
  • 41
    15-32057A1 SHIM, ROLLER BEARING CUP TO RETAINER (.002-3-5-10-25)
    SHIM, ROLLER BEARING CUP TO RETAINER (.002-3-5-10-25)
  • 42
    31-30894A3 TAPERED ROLLER BEARING ASSEMBLY, PINION GEAR
    TAPERED ROLLER BEARING ASSEMBLY, PINION GEAR
  • 43
    23-32066 SPACER, PINION GEAR ROLLER BEARING CUPS
    SPACER, PINION GEAR ROLLER BEARING CUPS
  • 44
    53-32185 RING, RETAINING - PINION GEAR ROLLER CUP TO RETAINER
    RING, RETAINING - PINION GEAR ROLLER CUP TO RETAINER
  • 45
    12-32073 WASHER, PINION GEAR TO UNIVERSAL JOINT NUT
    WASHER, PINION GEAR TO UNIVERSAL JOINT NUT
  • 46
    11-858869 NUT, PINION GEAR TO UNIVERSAL JOINT
    NUT, PINION GEAR TO UNIVERSAL JOINT
  • 46
    92-271091 ADHESIVE COMPOUND (3 1/2 UNCE KIT), EMBLEM FASTENING
    ADHESIVE COMPOUND (3 1/2 UNCE KIT), EMBLEM FASTENING
