GIMBAL RING ASSEMBLY AND STEERING LEVER для Mercruiser - 160 1967-1969 2065190 THRU 2763441

  • №
    Артикул
    Название
  • 1
    87356A1 GIMBAL RING ASSEMBLY
    GIMBAL RING ASSEMBLY
  • 2
    31-32538 BEARING, ROLLER - GIMBAL RING
    BEARING, ROLLER - GIMBAL RING
  • 3
    26-32541 OIL SEAL, GIMBAL RING
    OIL SEAL, GIMBAL RING
  • 4
    23-39273 SPACER, GIMBAL RING
    SPACER, GIMBAL RING
  • 5
    22-69059 FITTING, GREASE - GIMBAL RING
    FITTING, GREASE - GIMBAL RING
  • 6
    19-77633Q LUBRICAP, GIMBAL RING GREASE FITTING
    LUBRICAP, GIMBAL RING GREASE FITTING
  • 7
    17-77361A1 PIN, HINGE - GIMBAL RING TO BELL HOUSING
    PIN, HINGE - GIMBAL RING TO BELL HOUSING
  • 8
    17-77039 PIN, HINGE PIN RETAINING - GIMBAL RING
    PIN, HINGE PIN RETAINING - GIMBAL RING
  • 9
    39672A1 TILT STOP SWITXH ASS'V, GIMBAL RING (STANDARD AND POWER TIL)
    TILT STOP SWITXH ASS'V, GIMBAL RING (STANDARD AND POWER TIL)
  • 9
    45942A1 TILT STOP SWITXH ASS'Y, GIMBAL RING ( POWER TRIM)
    TILT STOP SWITXH ASS'Y, GIMBAL RING ( POWER TRIM)
  • 10
    10-20367 SCREW, TILT STOP SWITCH COVER TO GIMBAL RING (7/16")
    SCREW, TILT STOP SWITCH COVER TO GIMBAL RING (7/16")
  • 11
    31899 PLATE. RETAINING - TILT STOP SWITCHT TO GIMBAL RING
    PLATE. RETAINING - TILT STOP SWITCHT TO GIMBAL RING
  • 12
    10-45862 SCREW, RETAINING PLAT AND STRAP TO GIMBAL RING(7/8 )
    SCREW, RETAINING PLAT AND STRAP TO GIMBAL RING(7/8 )
  • 13
    32637 STRA, TILT STOP SWITCH RETAINING
    STRA, TILT STOP SWITCH RETAINING
  • 14
    11-20110 NUT, RETAINING PLATE AND STRAP SCREW
    NUT, RETAINING PLATE AND STRAP SCREW
  • 15
    49343 LEVER, TILT STOP SWITCH ACTUATING - GIMBAL RING
    LEVER, TILT STOP SWITCH ACTUATING - GIMBAL RING
  • 16
    10-31903 SCREW, TILT STOP SWITCH ACTUATING LEVER TO GIMBAL RING (3/8)
    SCREW, TILT STOP SWITCH ACTUATING LEVER TO GIMBAL RING (3/8)
  • 17
    88771A1 STEERING LEVER ASSEMBLY, UPPER SWIVEL SHAFT
    STEERING LEVER ASSEMBLY, UPPER SWIVEL SHAFT
  • 18
    23-48428 SLEEVE, STREERING LEVER
    SLEEVE, STREERING LEVER
  • 19
    32582 SHAFT, UPPER SWIVEL - GIMBAL RING TO GIMBAL HOUSING
    SHAFT, UPPER SWIVEL - GIMBAL RING TO GIMBAL HOUSING
  • 20
    22-32561 PLUG, PIPE - UPPER SWIVEL SHAFT
    PLUG, PIPE - UPPER SWIVEL SHAFT
  • 21
    12-32996 WASHER, UPPER SWIVEL SHAFT (.015)
    WASHER, UPPER SWIVEL SHAFT (.015)
  • 21
    12-32997 WASHER, UPPER SWIVEL SHAFT (.063)
    WASHER, UPPER SWIVEL SHAFT (.063)
  • 22
    10-807204 SCREW, STREERING LEVER TO UPPER SHAFT (2 )
    SCREW, STREERING LEVER TO UPPER SHAFT (2 )
  • 23
    11-20696 NUT, STEERING LEVER TO UPPER SWIVEL SHAFT SCREW
    NUT, STEERING LEVER TO UPPER SWIVEL SHAFT SCREW
  • 24
    10-45833 SCREW, UPPER SWIVEL SHAFT RETAINING - GIMBAL RING (2 1/2")
    SCREW, UPPER SWIVEL SHAFT RETAINING - GIMBAL RING (2 1/2")
  • 25
    12-20546 WASHER, UPPER SWIVEL SHAFT RETAINING SCREW
    WASHER, UPPER SWIVEL SHAFT RETAINING SCREW
  • 26
    16-32568 STUD, PIVOT - STEERING LEVER (2 21/32 )
    EARLY STYLE
    STUD, PIVOT - STEERING LEVER (2 21/32 )
    EARLY STYLE
  • 27
    12-25909 WASHER, STEERING ;EVER PIVOT STUD
    EARLY STYLE
    WASHER, STEERING ;EVER PIVOT STUD
    EARLY STYLE
  • 28
    12-29330 WASHER, NYLON - STEERING LEVEL PIVOT STUD
    EARLY STYLE
    WASHER, NYLON - STEERING LEVEL PIVOT STUD
    EARLY STYLE
  • 29
    79278 ROD, STEERING LINK - STEERING LEVER PIVOT STUD
    EARLY STYLE
    ROD, STEERING LINK - STEERING LEVER PIVOT STUD
    EARLY STYLE
  • 30
    29698 BALL, STEERING LEVER PIVOT
    EARLY STYLE
    BALL, STEERING LEVER PIVOT
    EARLY STYLE
  • 31
    24-20510 SPRING, STEERING LEVER PIVOT STUD
    EARLY STYLE
    SPRING, STEERING LEVER PIVOT STUD
    EARLY STYLE
  • 32
    23-31293 BUSHING, STEERING LEVER PIVOT STUD
    EARLY STYLE
    BUSHING, STEERING LEVER PIVOT STUD
    EARLY STYLE
  • 33
    11-8M0042636 NUT, STEERING LEVER PIVOT
    EARLY STYLE
    NUT, STEERING LEVER PIVOT
    EARLY STYLE
  • 34
    12-20086 WASHER, STEERING LINK ROD
    EARLY STYLE
    WASHER, STEERING LINK ROD
    EARLY STYLE
  • 35
    11-8M0042636 NUT, STEERING LINK ROD
    EARLY STYLE
    NUT, STEERING LINK ROD
    EARLY STYLE
  • 36
    68291A2 STEERING, LINK ROD ASSEMBLY
    LATE STYLE
    STEERING, LINK ROD ASSEMBLY
    LATE STYLE
  • 37
    23-48428 SLEEVE, STEERING LINK ROD (STEEL)
    LATE STYLE
    SLEEVE, STEERING LINK ROD (STEEL)
    LATE STYLE
  • 37
    23-52698 SLEEVE, STEERING LINK ROD (NYLON)
    LATE STYLE
    SLEEVE, STEERING LINK ROD (NYLON)
    LATE STYLE
  • 38
    12-20086 WASHER, STEERING LINK ROD
    LATE STYLE
    WASHER, STEERING LINK ROD
    LATE STYLE
  • 39
    11-8M0042636 NUT, STEERING LINK ROD
    LATE STYLE
    NUT, STEERING LINK ROD
    LATE STYLE
  • 40
    17-35813A1 PIN, TILT ADJUSTMENT - GIMBSL PIN
    PIN, TILT ADJUSTMENT - GIMBSL PIN
  • 41
    11-826709111 NUT, TILT ADJUSTMENT PIN
    NUT, TILT ADJUSTMENT PIN
