REVERSE LOCK VALVE AND SHIFT ACTUATOR (STERN DRIVE) для Mercruiser - 255 FORD 351 V-8 1973-1974 3258728 THRU 4175499

  • №
    Артикул
    Название
  • 1
    54951A2 REVERSE LOCK VALVE ASSEMBLY
    REVERSE LOCK VALVE ASSEMBLY
  • 2
    22-48166 FITTING, STRIGHT-REVERSE LOCK VALVE
    FITTING, STRIGHT-REVERSE LOCK VALVE
  • 3
    22-52666 ELBOW, REVERSE LOCK VALVE
    ELBOW, REVERSE LOCK VALVE
  • 4
    10-22485 SCREW, REVERSE LOCK VALVE TO CONTROL VALVE (3/4")
    SCREW, REVERSE LOCK VALVE TO CONTROL VALVE (3/4")
  • 5
    12-20583 WASHER, REVERSE LOCK VALVE SCREW
    WASHER, REVERSE LOCK VALVE SCREW
  • 6
    11-20184 NUT, REVERSE LOCK VALVE SCREW
    NUT, REVERSE LOCK VALVE SCREW
  • 7
    69392A4 SHIFT ACTUATOR ASSEMLBY(SEE D14 FOR BREAKDOWNAA)
    SHIFT ACTUATOR ASSEMLBY(SEE D14 FOR BREAKDOWNAA)
  • 8
    63038 COVER,SHIFT ACTUATOR
    COVER,SHIFT ACTUATOR
  • 9
    12-22887 WASHER, TERMINAL BLOCK AND COVER SCREW
    WASHER, TERMINAL BLOCK AND COVER SCREW
  • 10
    13-26996 LOCKWASERH, TERMINAL BVLOCK AND COVER SCREW
    LOCKWASERH, TERMINAL BVLOCK AND COVER SCREW
  • 11
    11-68219 NUT< TERMIANLBLOCK AND COVER SCREW
    NUT< TERMIANLBLOCK AND COVER SCREW
  • 12
    86-43454 TERMINAL BLOCK, MOUNTING BRACKET
    TERMINAL BLOCK, MOUNTING BRACKET
  • 13
    10-73656 SCREW, TERMINAL BLOCK AND COVER TO BRACKET (1 3/8")
    SCREW, TERMINAL BLOCK AND COVER TO BRACKET (1 3/8")
  • 14
    13-26996 LOCKWASHER, TERMINAL BLOCK AND COVER SCREW
    LOCKWASHER, TERMINAL BLOCK AND COVER SCREW
  • 15
    23-61526 SPACER, TERMINAL BLOCK AND COVER SCREW
    SPACER, TERMINAL BLOCK AND COVER SCREW
  • 16
    11-24656 NUT, TERMIANL BLOCK AND COVER SCREW
    NUT, TERMIANL BLOCK AND COVER SCREW
  • 17
    10-36046 SCREW, HARNESS TO TERMINAL BLOCK(1/4')
    SCREW, HARNESS TO TERMINAL BLOCK(1/4')
  • 18
    85821A1 BRACKET ASSEMBLY< MOUNTING--SHIFT ACTUATOR
    BRACKET ASSEMBLY< MOUNTING--SHIFT ACTUATOR
  • 19
    10-69028 SCREW, STOP (3/4")
    SCREW, STOP (3/4")
  • 20
    11-20184 NUT,STOP SCREW
    NUT,STOP SCREW
  • 21
    10-34290 SCREW, SHIFT ACTUATOR TO MOUNTING BRACKET (5/8")
    SCREW, SHIFT ACTUATOR TO MOUNTING BRACKET (5/8")
  • 22
    13-26992 LOCKWASHER, SHIFT ACTUATOR SCREW
    LOCKWASHER, SHIFT ACTUATOR SCREW
  • 23
    39670A10 SWITCH, ASSEMBLY, CUT OUTF
    SWITCH, ASSEMBLY, CUT OUTF
  • 24
    10-30902 SWITCH TO CONTROL VALVE CAP (3/4")
    SWITCH TO CONTROL VALVE CAP (3/4")
  • 25
    10-25299 SCREW, MOUNTIN BRACKET TO CONTROL VALVE (3/4")
    SCREW, MOUNTIN BRACKET TO CONTROL VALVE (3/4")
  • 26
    13-39107 LOCKWASHER, CONTROL VALVE BRACKET SCREW
    LOCKWASHER, CONTROL VALVE BRACKET SCREW
