INTAKE MANIFOLD AND THROTTLE LINKAGE(165-170-3.7L) для Mercruiser - 3.7LX (4 BBL.) MERCURY 224 I/L4 1988-1989 0B775249 & Up

  • №
    Артикул
    Название
  • 1
    89953A2 MANIFOLD ASSEMBLY, Intake
    MANIFOLD ASSEMBLY, Intake
  • 2
    22-36382 FITTING, (.250-18 x .62) Brass, INTAKE MANIFOLD - TOP
    FITTING, (.250-18 x .62) Brass, INTAKE MANIFOLD - TOP
  • 3
    10-28642 SCREW, (#2 x 0.25), DRIVE - WATER TUPE FLANGE
    SCREW, (#2 x 0.25), DRIVE - WATER TUPE FLANGE
  • 4
    27-70905 GASKET, INTAKE MANIFOLD
    GASKET, INTAKE MANIFOLD
  • 5
    10-68101 SCREW, (.375-16 x 1.375)
    SCREW, (.375-16 x 1.375)
  • 6
    12-25909 WASHER, (.406 x .812 x .065), INTAKE MANIFOLD SCREW
    WASHER, (.406 x .812 x .065), INTAKE MANIFOLD SCREW
  • 7
    22-73817 CONNECTOR, (90 Degree), INTAKE MANIFOLD
    CONNECTOR, (90 Degree), INTAKE MANIFOLD
  • 8
    32-89713 HOSE, INTAKE MANIFOLD TO RESERVIOR
    HOSE, INTAKE MANIFOLD TO RESERVIOR
  • 9
    54-815504104 CLAMP, HOSE ATTACHING
    CLAMP, HOSE ATTACHING
  • 10
    78801T LEVER, INTERMEDIATE THROTTLE
    LEVER, INTERMEDIATE THROTTLE
  • 11
    12-35950 WASHER, (.273 x .437 x .031) Stainless Steel, INTERMEDIATE THROTTLE STUD
    WASHER, (.273 x .437 x .031) Stainless Steel, INTERMEDIATE THROTTLE STUD
  • 12
    12-30164 WASHER, (.192 x .375 x .0312) Stainless Steel, INTERMEDIATE THROTTLE STUD
    WASHER, (.192 x .375 x .0312) Stainless Steel, INTERMEDIATE THROTTLE STUD
  • 13
    11-20110 NUT, (#10-32), INTERMEDIATE THROTTLE STUD
    NUT, (#10-32), INTERMEDIATE THROTTLE STUD
  • 14
    10-38507 SCREW, (5/16-18 x 1.313), LEVER TO INTAKE MANIFOLD (1-5/16")
    SCREW, (5/16-18 x 1.313), LEVER TO INTAKE MANIFOLD (1-5/16")
  • 15
    12-20553 WASHER, (.406 x .734 x .063), LEVER SCREW
    WASHER, (.406 x .734 x .063), LEVER SCREW
  • 16
    12-57792 WASHER, LEVER SCREW
    WASHER, LEVER SCREW
  • 17
    27947 SWIVEL, LINKAGE
    SWIVEL, LINKAGE
  • 18
    64804 LINK ROD, LINKAGE
    LINK ROD, LINKAGE
  • 19
    63145A1 LINK ROD ASSEMBLY, LINKAGE
    LINK ROD ASSEMBLY, LINKAGE
  • 20
    38983 SWIVEL, LINKAGE - CARBURETOR
    SWIVEL, LINKAGE - CARBURETOR
  • 21
    12-35950 WASHER, (.273 x .437 x .031) Stainless Steel, SWIVEL LINKAGE - CARBURETOR
    WASHER, (.273 x .437 x .031) Stainless Steel, SWIVEL LINKAGE - CARBURETOR
  • 22
    12-30164 WASHER, (.192 x .375 x .0312) Stainless Steel, SWIVEL LINKAGE - CARBURETOR
    WASHER, (.192 x .375 x .0312) Stainless Steel, SWIVEL LINKAGE - CARBURETOR
  • 23
    11-20110 NUT, (#10-32), SWIVEL LINKAGE - CARBURETOR
    NUT, (#10-32), SWIVEL LINKAGE - CARBURETOR
  • 24
    16-38525 STUD, THROTTLE CABLE ANCHOR
    STUD, THROTTLE CABLE ANCHOR
  • 25
    12-24664 WASHER, (M4 x 20), THROTTLE CABLE ANCHOR STUD
    WASHER, (M4 x 20), THROTTLE CABLE ANCHOR STUD
  • 26
    11-826709109 NUT, (.250-28), THROTTLE CABLE ANCHOR STUD
    NUT, (.250-28), THROTTLE CABLE ANCHOR STUD
  • 27
    10-64969 SCREW, THROTTLE STOP
    SCREW, THROTTLE STOP
  • 28
    11-33122 NUT, THROTTLE STOP SCREW
    NUT, THROTTLE STOP SCREW
  • 29
    32-76326 HOSE, INTAKE MANIFOLD TO WATER PUMP
    HOSE, INTAKE MANIFOLD TO WATER PUMP
  • 30
    54-815504220 CLAMP, HOSE TO WATER PUMP
    CLAMP, HOSE TO WATER PUMP
  • 31
    54-815504228 CLAMP, HOSE TO INTAKE MANIFOLD
    CLAMP, HOSE TO INTAKE MANIFOLD
  • 32
    32-89655 HOSE, INTAKE MANIFOLD
    HOSE, INTAKE MANIFOLD
  • 33
    54-815504228 CLAMP, HOSE TO INTAKE MANIFOLD
    CLAMP, HOSE TO INTAKE MANIFOLD
  • -
    27-43186A1 GASKET SET
    GASKET SET
