INDUCTION MANIFOLD для Mariner - 30 (2 CYL.) 9854537 THRU 0P016999

  • №
    Артикул
    Название
  • 1
    821371A3 MANIFOLD ASSEMBLY, Induction
    SN# USA 0G380074, BEL 9905360 & Below
    MANIFOLD ASSEMBLY, Induction
    SN# USA 0G380074, BEL 9905360 & Below
  • 1
    821371A2 MANIFOLD ASSEMBLY, Induction
    SN# USA 0G380075, BEL 9905361 & Up
    MANIFOLD ASSEMBLY, Induction
    SN# USA 0G380075, BEL 9905361 & Up
  • 2
    21-426233 CHECK VALVE
    CHECK VALVE
  • 3
    22-823563 FITTING (BARBED)
    FITTING (BARBED)
  • 4
    NSS NOT SOLD SEPARATE, DOWEL PIN (COMPONENT OF REF #1)
    SN# USA 0G380074, BEL 9905360 & Below
    NOT SOLD SEPARATE, DOWEL PIN (COMPONENT OF REF #1)
    SN# USA 0G380074, BEL 9905360 & Below
  • 5
    16-8161949 STUD (M6 X 1 X 44)
    STUD (M6 X 1 X 44)
  • 6
    10-82130040 STUD (M6 X 1 X 55)(STUD ATTACHING)
    STUD (M6 X 1 X 55)(STUD ATTACHING)
  • 7
    10-82130040 SCREW, (M6 x 40) (SCREW ATTACHING)
    SCREW, (M6 x 40) (SCREW ATTACHING)
  • 8
    32-892024122 TUBING, (20.00 Feet Bulk) (Cut to 12 1/2 IN.)
    TUBING, (20.00 Feet Bulk) (Cut to 12 1/2 IN.)
  • 9
    10-81742730 SCREW, (M8 x 30)
    SN# USA 0G380075, BEL 9905361 & Up
    SCREW, (M8 x 30)
    SN# USA 0G380075, BEL 9905361 & Up
  • 9
    10-40011149 SCREW, (M8 x 25) Stainless Steel (HEX FLANGE HEAD)
    SN# BEL 9905360- 9905385, USA 0G380074 & Below
    SCREW, (M8 x 25) Stainless Steel (HEX FLANGE HEAD)
    SN# BEL 9905360- 9905385, USA 0G380074 & Below
  • 10
    34-812880A03 REED ASSEMBLY
    SN# BEL 9905360- 9905385, USA 0G380074 & Below
    REED ASSEMBLY
    SN# BEL 9905360- 9905385, USA 0G380074 & Below
  • 11
    14-429821 TAB WASHER
    SN# BEL 9905360- 9905385, USA 0G380074 & Below
    TAB WASHER
    SN# BEL 9905360- 9905385, USA 0G380074 & Below
  • 12
    812879002 RETAINER, Reed
    (40 H.P.) SN# BEL 9905360- 9905385, USA 0G380074 & Below
    RETAINER, Reed
    (40 H.P.) SN# BEL 9905360- 9905385, USA 0G380074 & Below
  • 13
    825267 RETAINER, Reed
    (30 H.P.) SN# BEL 9905360- 9905385, USA 0G380074 & Below
    RETAINER, Reed
    (30 H.P.) SN# BEL 9905360- 9905385, USA 0G380074 & Below
  • 14
    10-4000171 SCREW, (M6 x 16) (HEX HEAD CAP)
    SN# BEL 9905360- 9905385, USA 0G380074 & Below
    SCREW, (M6 x 16) (HEX HEAD CAP)
    SN# BEL 9905360- 9905385, USA 0G380074 & Below
  • 15
    27-821370 GASKET
    SN# BEL 9905360- 9905385, USA 0G380074 & Below
    GASKET
    SN# BEL 9905360- 9905385, USA 0G380074 & Below
  • 16
    830246T2 REED VALVE
    (30 H.P.) SN# USA 0G380075, BEL 9905361 & Up
    REED VALVE
    (30 H.P.) SN# USA 0G380075, BEL 9905361 & Up
  • 16
    830246T3 REED VALVE
    SN# USA 0G380075, BEL 9905361 & Up
    REED VALVE
    SN# USA 0G380075, BEL 9905361 & Up
  • -
    27-822420A94 GASKET SET
    GASKET SET
  • -
    808569T02 POWERHEAD ASSEMBLY
    POWERHEAD ASSEMBLY
