LIGHTING SYSTEM для Ktm 250R FREERIDE - 2017 года выпуска

  • №
    Артикул
    Название
  • 1
    81214001000 HEAD LIGHT
    HEAD LIGHT
  • 2
    54814001050 RUBBER CAP FOR HEAD LIGHT
    RUBBER CAP FOR HEAD LIGHT
  • 3
    44111038000 BILUX-BULB 12V 35/35W BA20D
    BILUX-BULB 12V 35/35W BA20D
  • 4
    0081050181 SCREW FOR PLASTIC K50X18 T20
    SCREW FOR PLASTIC K50X18 T20
  • 5
    0912050503 AH SCREW DIN912-M5X50
    AH SCREW DIN912-M5X50
  • 6
    72008008000 DIST. HOSE F. HEAD LIGHT MASK
    DIST. HOSE F. HEAD LIGHT MASK
  • 7
    49011435100 BULB 12V 5W (W2,1X9,5D) PHIL.
    BULB 12V 5W (W2,1X9,5D) PHIL.
  • 8
    54811001050 CABLE FOR HEAD LIGHT
    CABLE FOR HEAD LIGHT
  • 9
    81208003010 INSERT FOR HEAD LIGHT SUPPORT
    INSERT FOR HEAD LIGHT SUPPORT
  • 20
    72514040000 REAR LIGHT
    REAR LIGHT
  • 25
    75014047000 LICENSE PLATE ILLUMINATION
    LICENSE PLATE ILLUMINATION
  • 26
    72511081000 FLASHER HARNESS
    FLASHER HARNESS
  • 28
    0081250181 SCREW FOR PLASTIC 50X18 T20
    SCREW FOR PLASTIC 50X18 T20
  • 29
    0017060205 SCREW FOR PLASTIC K60X20
    SCREW FOR PLASTIC K60X20
  • 30
    54814025200 FLASHER CPL. FR.L/S RE.R/S
    FLASHER CPL. FR.L/S RE.R/S
  • 31
    54814026200 FLASHER CPL. FR.R/S RE.L/S
    FLASHER CPL. FR.R/S RE.L/S
  • 32
    44111015100 BULB 12V 10W
    BULB 12V 10W
  • 33
    0125100003 WASHER DIN0125-A10,5
    WASHER DIN0125-A10,5
  • 34
    0797100003 LOCK WASHER DIN6797-J10,5 ZI
    LOCK WASHER DIN6797-J10,5 ZI
  • 35
    58414030000 HH COLLAR NUT M10X1,25
    HH COLLAR NUT M10X1,25
  • 36
    54814028000 FLASHER LENS L/S R/S
    FLASHER LENS L/S R/S
