LIGHTING SYSTEM для Ktm 1190 RC8R - 2013 года выпуска

  • №
    Артикул
    Название
  • 1
    69314001000 HEADLIGHT LED
    HEADLIGHT LED
  • 2
    60014003100 BULB H7 12V 55W
    BULB H7 12V 55W
  • 4
    49011435100 BULB 12V 5W (W2,1X9,5D) PHIL.
    BULB 12V 5W (W2,1X9,5D) PHIL.
  • 5
    69008021080 RANGE CHANGE METAL NUT M5
    RANGE CHANGE METAL NUT M5
  • 6
    69014001050 RUBBER CAP FOR HEADLIGHT
    RUBBER CAP FOR HEADLIGHT
  • 7
    69011076000 WIRING HARN. NUMB.-PLATE ILLU.
    WIRING HARN. NUMB.-PLATE ILLU.
  • 8
    6901401110033 HEAD LIGHT BRACKET R/S
    HEAD LIGHT BRACKET R/S
  • 9
    6901401000033 HEAD LIGHT BRACKET L/S
    HEAD LIGHT BRACKET L/S
  • 10
    75014047000 LICENSE PLATE ILLUMINATION
    LICENSE PLATE ILLUMINATION
  • 13
    69014040000 REAR LIGHT CPL.
    REAR LIGHT CPL.
  • 14
    69014017000 SPECIAL SCREW M6X18 ISA30
    SPECIAL SCREW M6X18 ISA30
  • 15
    69014014000 BUSHING 6,1X9,2X7,5
    BUSHING 6,1X9,2X7,5
  • 16
    60006001022 RUB.SLEEVE FLOAT CHAMB.VENTING
    RUB.SLEEVE FLOAT CHAMB.VENTING
  • 17
    0081050161 EJOT PT SCREW K50X16 1451
    EJOT PT SCREW K50X16 1451
  • 18
    69014015000 BUSHING HEAD LIGHT
    BUSHING HEAD LIGHT
  • 19
    0081040161 SCREW FOR PLASTIC K40X16 T20
    SCREW FOR PLASTIC K40X16 T20
  • 20
    69014078000 RUBBER SLEEVE 10X14X20
    RUBBER SLEEVE 10X14X20
  • 21
    69014526100 FLASHER FR.R/S / RE.L/S
    FLASHER FR.R/S / RE.L/S
  • 22
    69014525100 FLASHER FR.L/S / RE.R/S
    FLASHER FR.L/S / RE.R/S
