FRONT FORK для Ktm 950 SUPERDUKE - 2005 года выпуска

  • №
    Артикул
    Название
  • 1
    14187A13LS FORK LEG L/S WP48
    FORK LEG L/S WP48
  • 2
    14187A13RS FORK LEG R/S WP48
    FORK LEG R/S WP48
  • 3
    0912080303 AH SCREW DIN0912-M 8X30
    AH SCREW DIN0912-M 8X30
  • 4
    61001034026 TOP TRIPLE CLAMP 210/26
    TOP TRIPLE CLAMP 210/26
  • 5
    61001032026 BOT.TRIPLE CLAMP CPL.
    BOT.TRIPLE CLAMP CPL.
  • 6
    60001033000 FORK TUBE
    FORK TUBE
  • 7
    0015080303 HH COLLAR SCREW M 8X30 WS=10
    HH COLLAR SCREW M 8X30 WS=10
  • 8
    59001037000 SPECIAL SCREW M8X26 WS=10
    SPECIAL SCREW M8X26 WS=10
  • 9
    0934080003 HEXAGON NUT DIN0934-M 8
    HEXAGON NUT DIN0934-M 8
  • 10
    54601084100 O-RING SUPPORT W. SEALING LIP
    O-RING SUPPORT W. SEALING LIP
  • 11
    54201081000 TAPERED ROLLER BEARING CPL.
    TAPERED ROLLER BEARING CPL.
  • 12
    54601184000 STEARING HEAD GASKET TOP
    STEARING HEAD GASKET TOP
  • 13
    61001086000 STEERING HEAD COVER
    STEERING HEAD COVER
  • 14
    54801036000 STEER.HEAD SCREW M20X1,5 WS=27
    STEER.HEAD SCREW M20X1,5 WS=27
  • 15
    59001038300 HANDLEBAR CAMP 28MM ELOX.
    HANDLEBAR CAMP 28MM ELOX.
  • 16
    0012100603 AH SCREW DIN6912-M10X60
    AH SCREW DIN6912-M10X60
  • 17
    59001039200 HANDLEBAR SUPPORT 28 MM ELOX.
    HANDLEBAR SUPPORT 28 MM ELOX.
  • 18
    56401042000 WASHER 10,5X32X2
    WASHER 10,5X32X2
  • 19
    56401040000 RUBBER BUSHING
    RUBBER BUSHING
  • 20
    61001041000 SPACER TUBE 10,2X12X38
    SPACER TUBE 10,2X12X38
  • 21
    0982100003 SELF LOCK.NUT DIN0982-M10 HIGH
    SELF LOCK.NUT DIN0982-M10 HIGH
