FRAME W/ SUB FRAME для Ktm LC4 640 Adventure - 2003 года выпуска

  • №
    Артикул
    Название
  • 1
    5820300154490 FRAME CPL.
    FRAME CPL.
  • 2
    5840300234490 SUBFRAME CPL. STEEL SILVER
    SUBFRAME CPL. STEEL SILVER
  • 4
    58303002090 PLUG 12 X 17 MM
    PLUG 12 X 17 MM
  • 5
    5810300320090 FOOTRESTBRACK. REAR L/S SILVER
    FOOTRESTBRACK. REAR L/S SILVER
  • 5
    5810300420090 FOOTRESTBRACK. REAR R/S SILVER
    FOOTRESTBRACK. REAR R/S SILVER
  • 7
    0934080003 HEXAGON NUT DIN0934-M 8
    HEXAGON NUT DIN0934-M 8
  • 10
    59001037000 SPECIAL SCREW M8X26 WS=10
    SPECIAL SCREW M8X26 WS=10
  • 11
    58003012000 SPACER ROLLER 10,3X20X22
    SPACER ROLLER 10,3X20X22
  • 12
    71001012100 PVC CAP D=22MM
    PVC CAP D=22MM
  • 13
    58307015000 TANK SUPPORT
    TANK SUPPORT
  • 14
    58303055000 ENGINE SUPPORT AGW
    ENGINE SUPPORT AGW
  • 16
    58403013000 ENGINE BRAC.SCREW M10X110 WS13
    ENGINE BRAC.SCREW M10X110 WS13
  • 17
    54630044000 COLLAR NUT M10 WS=13
    COLLAR NUT M10 WS=13
  • 18
    49109481052 HH COLLAR SCREW M 8X16 WS=13
    HH COLLAR SCREW M 8X16 WS=13
  • 19
    54310086200 SELF LOCKING NUT M8 10.9
    SELF LOCKING NUT M8 10.9
  • 20
    58403002370 BATTERY BOX
    BATTERY BOX
  • 21
    0015060103 HH COLLAR SCREW M 6X10 WS=8
    HH COLLAR SCREW M 6X10 WS=8
  • 22
    0021060003 WASHER DIN9021-A 6,4
    WASHER DIN9021-A 6,4
  • 23
    43205062100 RUBBER GROMMET 20X15-M6X10 (1)
    RUBBER GROMMET 20X15-M6X10 (1)
  • 24
    0797060003 TOOTH LOCK WASH. DIN6797-A 6,4
    TOOTH LOCK WASH. DIN6797-A 6,4
  • 25
    0934060003 HEXAGON NUT DIN0934-M 6
    HEXAGON NUT DIN0934-M 6
  • 26
    58403002010 RUBBER GROMMET 20X15-M6X8-(2)
    RUBBER GROMMET 20X15-M6X8-(2)
  • 27
    54603048100 RANGE CHANGE METAL NUT M6
    RANGE CHANGE METAL NUT M6
  • 30
    0931100603 HH SCREW DIN0931-M10X60
    HH SCREW DIN0931-M10X60
  • 31
    0982100003 SELF LOCK.NUT DIN0982-M10 HIGH
    SELF LOCK.NUT DIN0982-M10 HIGH
  • 32
    58403014000 ENGINE BRAC.SCREW M10X160 WS13
    ENGINE BRAC.SCREW M10X160 WS13
  • 36
    55007016001 3 PVC-HOSE 7X10 PER METRE
    PVC-HOSE 7X10 PER METRE
  • 37
    50303089000 ANGEL PIECE
    ANGEL PIECE
  • 38
    5830303800090 FOOTREST BRACKET L/S SILVER'99
    FOOTREST BRACKET L/S SILVER'99
  • 40
    5830304000090 FOOTREST L/S SILVER
    FOOTREST L/S SILVER
  • 41
    5460314000090 FOOT REST R/S SILVER
    FOOT REST R/S SILVER
  • 42
    58303041000 FOOTREST SPRING L/S
    FOOTREST SPRING L/S
  • 43
    54603041000 FOOTREST SPRING L/S & R/S
    FOOTREST SPRING L/S & R/S
  • 44
    58303044000 BOLT FOR FOOTREST
    BOLT FOR FOOTREST
  • 45
    54603044000 BOLT FOR FOOTREST 9,8 X 50
    BOLT FOR FOOTREST 9,8 X 50
  • 46
    0125100003 WASHER DIN0125-A10,5
    WASHER DIN0125-A10,5
  • 47
    0094032253 PIN DIN0094-3,2X25 STEEL
    PIN DIN0094-3,2X25 STEEL
  • 50
    58303050044 FOOTREST REAR L/S CPL.
    FOOTREST REAR L/S CPL.
  • 50
    58303150044 FOOT REST REAR R/S CPL.
    FOOT REST REAR R/S CPL.
  • 51
    58303045044 FOOTREST RUBBER CPL.
    FOOTREST RUBBER CPL.
  • 52
    58303051000 FOOTREST RUBBER L/S & R/S DUKE
    FOOTREST RUBBER L/S & R/S DUKE
  • 53
    58403060000 CHAIN ROLL 12X28X22
    CHAIN ROLL 12X28X22
  • 55
    58403060065 BUSH CHAIN ROLL 8X12X23
    BUSH CHAIN ROLL 8X12X23
  • 56
    0797080003 TOOTHLOCK WASHER DIN6797-J 8,4
    TOOTHLOCK WASHER DIN6797-J 8,4
  • 58
    0985060003 SELF LOCK. NUT DIN0985-M 6
    SELF LOCK. NUT DIN0985-M 6
  • 59
    51103053000 CHAIN SLIDING PIECE BELOW
    CHAIN SLIDING PIECE BELOW
  • 60
    51103053051 BUSHING 8,2X10X20
    BUSHING 8,2X10X20
  • 61
    54403135000 PLASTIC CAP SFL10
    PLASTIC CAP SFL10
  • 68
    36003014000 LOCK WASHER 8MM
    LOCK WASHER 8MM
  • 70
    0015080303 HH COLLAR SCREW M8 X30 WS=10
    HH COLLAR SCREW M8 X30 WS=10
  • 71
    0015080453 HH COLLAR SCREW M 8X45 WS=10
    HH COLLAR SCREW M 8X45 WS=10
  • 72
    0910160153 PLUG DIN0910-M16X1,5
    PLUG DIN0910-M16X1,5
  • 73
    0603162220 CU-SEAL RING 16X22X2
    CU-SEAL RING 16X22X2
  • 76
    54510052100 SPROCKET SCREW-AH M8X26 WS=6
    SPROCKET SCREW-AH M8X26 WS=6
  • 77
    0984060103 AH SCREW DIN7984-M 6X10
    AH SCREW DIN7984-M 6X10
  • 79
    0125080003 WASHER DIN0125-A 8,4
    WASHER DIN0125-A 8,4
  • 80
    58303010000 COVER OIL FILTER
    COVER OIL FILTER
  • 81
    0014060153 HH COLLAR SCREW M 6X15 WS=8
    HH COLLAR SCREW M 6X15 WS=8
  • 82
    0014060103 HH COLLAR SCREW M6X10 WS=8
    HH COLLAR SCREW M6X10 WS=8
  • 85
    50235033300 SNAP-NUT HOLDER M6 KP142
    SNAP-NUT HOLDER M6 KP142
  • 90
    58412099044 ENGINE PROTECT.LIMITED CPL.
    ENGINE PROTECT.LIMITED CPL.
  • 91
    0014060103 HH COLLAR SCREW M6X10 WS=8
    HH COLLAR SCREW M6X10 WS=8
  • 93
    58003012200 ENGINE PROTECTOR BRACKET
    ENGINE PROTECTOR BRACKET
  • 94
    0014060153 HH COLLAR SCREW M 6X15 WS=8
    HH COLLAR SCREW M 6X15 WS=8
  • 95
    54308042000 RUBBER BUFFER
    RUBBER BUFFER
