BRAKE CALIPER REAR для Ktm 85 SX - 2003 года выпуска

  • №
    Артикул
    Название
  • 18
    47013118000 RETAINING SPRING REAR
    RETAINING SPRING REAR
  • 21
    47013021000 CAP FOR BLEEDER SCREW
    CAP FOR BLEEDER SCREW
  • 25
    47013225000 HOLLOW SCREW REAR
    HOLLOW SCREW REAR
  • 26
    47013325000 HOLLOW SCREW REAR
    HOLLOW SCREW REAR
  • 30
    0015080203 HH COLLAR SCREW M 8X20 WS=10
    HH COLLAR SCREW M 8X20 WS=10
  • 31
    0015080403 HH COLLAR SCREW M 8X40 WS=10
    HH COLLAR SCREW M 8X40 WS=10
  • 70
    47013070000 BRAKE HOSE REAR
    BRAKE HOSE REAR
  • 71
    0770080019 O-RING 8,00X1,00 EPDM
    O-RING 8,00X1,00 EPDM
  • 72
    0770100019 O-RING 10X1 EPDM
    O-RING 10X1 EPDM
  • 80
    47013080000 BRAKE CALIPER RE. CPL.
    BRAKE CALIPER RE. CPL.
  • 81
    47013081000 REPAIR KIT SEAL RING REAR
    REPAIR KIT SEAL RING REAR
  • 82
    46113125000 AH SCREW + CIRCLIP
    AH SCREW + CIRCLIP
  • 83
    0799040009 TAB WASHER DIN6799-RA 4,0
    TAB WASHER DIN6799-RA 4,0
  • 85
    47013085000 BLEEDER SCREW M8X1
    BLEEDER SCREW M8X1
  • 90
    47013090000 BRAKE PAD SET REAR
    BRAKE PAD SET REAR
