FORK LEGS (WHITE POWER) для Ktm LC4 640 Duke II - 2000 года выпуска`
-
№АртикулНазвание
-
148600020S SREW CAP+BUSH M51X1,5SREW CAP+BUSH M51X1,5
-
246810016 O-RING NBR 48X2O-RING NBR 48X2
-
348600018 KNOB REBOUNG ADJUSTERKNOB REBOUNG ADJUSTER
-
540540603 STEEL BALL D=3MMSTEEL BALL D=3MM
-
648600028 SPRING D=2,9 L=7,9SPRING D=2,9 L=7,9
-
748600044 O-RING NBR 6X1,5O-RING NBR 6X1,5
-
848600058 VENT SCREW M4X6VENT SCREW M4X6
-
948600009 O-RING NBR 3,7X1,6O-RING NBR 3,7X1,6
-
1048600043 O-RING NBR 12X1,5O-RING NBR 12X1,5
-
1148600019 HOLDER F.ADJUSTMENT TUBE D=4MMHOLDER F.ADJUSTMENT TUBE D=4MM
-
1243570176 OUTER TUBE L=577MM D=54/54MMOUTER TUBE L=577MM D=54/54MM
-
1543570019 DU-BUSH 47 X 43 X 20DU-BUSH 47 X 43 X 20
-
1643570092 SUPPORT RING 45 X 52,5 X 1,5SUPPORT RING 45 X 52,5 X 1,5
-
1743570140 OIL SEAL RING 43X53,15X9,5OIL SEAL RING 43X53,15X9,5
-
1843570008 LOCK WASHER SB53LOCK WASHER SB53
-
1943570094 DUST STRIPPER D=43MMDUST STRIPPER D=43MM
-
2243570020 DU-BUSH 43,8 X 43 X 20DU-BUSH 43,8 X 43 X 20
-
2343570064 INNER TUBE D=43MM L=550MMINNER TUBE D=43MM L=550MM
-
2443570142S HYDR.STOP L=200MM D=27,5 CPL.HYDR.STOP L=200MM D=27,5 CPL.
-
3048600131 ADJUSTMENT TUBE L=357MMADJUSTMENT TUBE L=357MM
-
3148600132 PISTONROD D=14MM L=391MM M11X1PISTONROD D=14MM L=391MM M11X1
-
3348600003 REBOUND NEEDLEREBOUND NEEDLE
-
3448600046 O-RING NBR 3X1,5O-RING NBR 3X1,5
-
3548600033 SPRING REBOUND NEEDLE C=4N/MMSPRING REBOUND NEEDLE C=4N/MM
-
3648600053 SPACER 42X26,5X1,5SPACER 42X26,5X1,5
-
3648600036 SPACER 42X26,5X2,5SPACER 42X26,5X2,5
-
3648600037 SPACER 42X26,5X5SPACER 42X26,5X5
-
3648600038 SPACER 42X26,5X10SPACER 42X26,5X10
-
3748600039 RING 26,5X42X1,5RING 26,5X42X1,5
-
3895010018S SPRING 7,0 N/MM SET D=4,9MMSPRING 7,0 N/MM SET D=4,9MM
-
3943570131 INTERM. RING 26,2X38,5X3INTERM. RING 26,2X38,5X3
-
4243570132S SCREW SLEEVE M29,3X1+BUSHSCREW SLEEVE M29,3X1+BUSH
-
4346810651 DU-BUSH 14X16X12DU-BUSH 14X16X12
-
4448600015 REBOUND SPRING D=14,6MM L=22MMREBOUND SPRING D=14,6MM L=22MM
-
4548600025 TAP REBOUNDTAP REBOUND
-
4748600059 SPRING CHECK VALVE D=0,25SPRING CHECK VALVE D=0,25
-
4948600062 CHECK VALVE 8X24X0,1CHECK VALVE 8X24X0,1
-
5040540400 SHIM 6X12X0,1SHIM 6X12X0,1
-
5040540401 SHIM 6X14X0,1SHIM 6X14X0,1
-
5040540402 SHIM 6X16X0,1SHIM 6X16X0,1
-
5040540403 SHIM 6X18X0,1SHIM 6X18X0,1
-
5040541402 SHIM 6X11X0,2SHIM 6X11X0,2
-
5040540404 SHIM 6X12X0,15SHIM 6X12X0,15
-
5040540405 SHIM 6X14X0,15SHIM 6X14X0,15
-
5040540406 SHIM 6X16X0,15SHIM 6X16X0,15
-
5040540407 SHIM 6X18X0,15SHIM 6X18X0,15
-
5040540410 SHIM 6X16X0,2SHIM 6X16X0,2
-
5040540411 SHIM 6X18X0,2SHIM 6X18X0,2
-
5040540414 SHIM 6X16X0,25SHIM 6X16X0,25
-
5040540447 SHIM 6X10X0,3SHIM 6X10X0,3
-
5040541383 SHIM 6X11X0,1SHIM 6X11X0,1
-
5040541391 SHIM 6X11X0,3SHIM 6X11X0,3
-
5048600063 SHIM 6X24X0,1SHIM 6X24X0,1
-
5048600064 SHIM 6X22X0,1SHIM 6X22X0,1
-
5048600065 SHIM 6X20X0,1SHIM 6X20X0,1
-
5048600066 SHIM 6X24X0,1SHIM 6X24X0,1
-
5048600067 SHIM 6X22X0,1SHIM 6X22X0,1
-
5148600060 PISTON RING 5X1X84PISTON RING 5X1X84
-
5248600042 PISTON REBOUNDPISTON REBOUND
-
5540540486 NUT M6X0,5 REBOUNDNUT M6X0,5 REBOUND
-
5848600133 TUBE 29,3X1X405 D=28MMTUBE 29,3X1X405 D=28MM
-
5940541241 CHECK VALVE NUT M6X0,5CHECK VALVE NUT M6X0,5
-
6043570178 AXLE CLAMP L/S DUKEAXLE CLAMP L/S DUKE
-
6143570179 AXLE CLAMP R/S DUKEAXLE CLAMP R/S DUKE
-
6240541278 SPRING CHECK VALVE D=0,5MMSPRING CHECK VALVE D=0,5MM
-
6448600061 CHECK VALVE 8X24X0,4CHECK VALVE 8X24X0,4
-
6546811499 O-RING NBR 21X2O-RING NBR 21X2
-
6648600047 PISTON COMPRESSIONPISTON COMPRESSION
-
6743570177 TAP COMPRESSIONTAP COMPRESSION
-
6835480320 O-RING NBR 24X2O-RING NBR 24X2
-
6948600004 COPPER WASHER 29,5X33,5X1COPPER WASHER 29,5X33,5X1
-
7043570023 O-RING NBR 41X2O-RING NBR 41X2
-
7248600034 COMPRESSION ADJ. SCREWCOMPRESSION ADJ. SCREW
-
7348600051 LOCK WASHER RB12LOCK WASHER RB12
-
7448600049 O-RING NBR 8X2O-RING NBR 8X2
-
7548600035 NEEDLE COMPRESSION M10X1NEEDLE COMPRESSION M10X1
-
7840540215 AH SCREW M 8X30AH SCREW M 8X30
-
790603122171 SEAL RING 12,2X17X1SEAL RING 12,2X17X1
-
8043570174 BOLT M12X1BOLT M12X1
-
9040540882 FORKOIL REZ 71 SAE 5FORKOIL REZ 71 SAE 5
