ELECTRONIC POWER CONTROL для Ktm LC4 640 Duke II - 2000 года выпуска

  • №
    Артикул
    Название
  • 1
    58431067000 MAGNETIC VALVE PIRBURG EPC
    MAGNETIC VALVE PIRBURG EPC
  • 2
    58431072000 T-CONNECTION 12MM
    T-CONNECTION 12MM
  • 3
    58431070000 AIR FILTER
    AIR FILTER
  • 4
    58431069000 BRACKET FOR MAGNETIC VALVE
    BRACKET FOR MAGNETIC VALVE
  • 5
    54635022000 SLEEVE FOR STEERING HEAD
    SLEEVE FOR STEERING HEAD
  • 6
    58431071000 VACUUM HOSE FOR MAGNETIC V.
    VACUUM HOSE FOR MAGNETIC V.
  • 7
    58431097000 ANGULAR HOSE T-CON.-CARBURETOR
    ANGULAR HOSE T-CON.-CARBURETOR
  • 8
    58431097100 TUBE 12MM T-CON.-FILTER
    TUBE 12MM T-CON.-FILTER
  • 10
    0912060404 AH SCREW DIN0912-M 6X40
    AH SCREW DIN0912-M 6X40
  • 11
    58431082000 YDNAC-CLAMP 15MM
    YDNAC-CLAMP 15MM
  • 12
    58431082100 YDNAC-CLAMP 16MM
    YDNAC-CLAMP 16MM
  • 20
    58431080000 BRACKET FOR ENDSWITCH
    BRACKET FOR ENDSWITCH
  • 21
    0084020103 CYL.HEAD SCREW DIN0084-M 2X10
    CYL.HEAD SCREW DIN0084-M 2X10
  • 22
    0934020003 HH NUT DIN0934-M 2
    HH NUT DIN0934-M 2
  • 23
    0015050123 HH COLLAR SCREW M 5X12 WS=8
    HH COLLAR SCREW M 5X12 WS=8
  • 24
    58431065100 MICRO SWITCH
    MICRO SWITCH
  • 30
    58011081100 CONTACT SCREW M10 STEEL
    CONTACT SCREW M10 STEEL
  • 32
    58411085000 WIRING HARN. EPC F. ENGINE
    WIRING HARN. EPC F. ENGINE
  • 35
    58431063100 CONTROL UNIT FOR EPC (DUKE)
    CONTROL UNIT FOR EPC (DUKE)
  • 37
    0014060103 HH COLLAR SCREW M 6X10 WS=8
    HH COLLAR SCREW M 6X10 WS=8
