FRONT FORK (WHITE POWER) для Ktm LC4 640 Adventure R - 2000 года выпуска
-
№АртикулНазвание
-
158201001100 FORK LEG WP "0918S755" (LEFT)FORK LEG WP "0918S755" (LEFT)
-
258201002100 FORK LEG WP "0918S755" (RIGHT)FORK LEG WP "0918S755" (RIGHT)
-
550301070000 SP.CABLE GUIDE MARZ.50,WP50SP.CABLE GUIDE MARZ.50,WP50
-
60015050203 HH COLLAR SCREW M 5X20 WS=8HH COLLAR SCREW M 5X20 WS=8
-
70985050003 SELF LOCKING NUT DIN0985-M 5SELF LOCKING NUT DIN0985-M 5
-
80015080253 HH COLLAR SCREW M 8X25 WS=10HH COLLAR SCREW M 8X25 WS=10
-
90015050163 HH COLLAR SCREW M 5X16 WS=8HH COLLAR SCREW M 5X16 WS=8
-
1050301092000 FORK PROTECTOR (LEFT) (BLACK)FORK PROTECTOR (LEFT) (BLACK)
-
1050301093000 FORK PROTECTOR (RIGHT) (BLACK)FORK PROTECTOR (RIGHT) (BLACK)
-
125460129000030 FORK PROTECTION GUIDE (LEFT)FORK PROTECTION GUIDE (LEFT)
-
125460139000030 FORK PROTECTION GUIDE (RIGHT)FORK PROTECTION GUIDE (RIGHT)
-
1350301090150 CLAMP PROTECTOR GUIDE SXC, ADVCLAMP PROTECTOR GUIDE SXC, ADV
-
1450301090250 CLAMP PROTECTOR GUIDECLAMP PROTECTOR GUIDE
-
1558402001050 SUPPORTKIT F. HANDLESUPPORTKIT F. HANDLE
-
300912080353 AH SCREW DIN0912-M 8X35AH SCREW DIN0912-M 8X35
-
3250301132016 BOT TRIPLE CLAMP X=16MM/D=50MMBOT TRIPLE CLAMP X=16MM/D=50MM
-
3350101033100 FORK TUBE L=244 '91FORK TUBE L=244 '91
-
3458201034016 TOP TRIPLE CLAMP X=16MM/D=50MMTOP TRIPLE CLAMP X=16MM/D=50MM
-
4056401040000 RUBBER BUSHINGRUBBER BUSHING
-
4156401041100 SPACER TUBE 10,2X12X44SPACER TUBE 10,2X12X44
-
4256401042000 WASHER 10,5X32X2WASHER 10,5X32X2
-
04256401142000 WASHER 10,5X31WASHER 10,5X31
-
4356401043000 HH SCREW M20X1,5HH SCREW M20X1,5
-
4456401044000 WASHER 21X38X3WASHER 21X38X3
-
530015080303 HH COLLAR SCREW M 8X30 WS=10HH COLLAR SCREW M 8X30 WS=10
-
540015080353 HH COLLAR SCREW M 8X35 WS=10HH COLLAR SCREW M 8X35 WS=10
-
570933080253 HH SCREW DIN0933-M 8X25HH SCREW DIN0933-M 8X25
-
580934080003 HEXAGON NUT DIN0934-M 8HEXAGON NUT DIN0934-M 8
-
590985100003 SELF LOCKING NUT DIN0985-M10SELF LOCKING NUT DIN0985-M10
-
8054601084100 O-RING SUPPORT W. SEALING LIPO-RING SUPPORT W. SEALING LIP
-
8154201081000 TAPERED ROLLER BEARINGTAPERED ROLLER BEARING
-
8354601184000 STEARING HEAD GASKET TOPSTEARING HEAD GASKET TOP
-
8654201086000 STEERING HEAD COVERSTEERING HEAD COVER
-
9954212035000 RING WRENCH WS=32RING WRENCH WS=32
