SECONDARY AIR SYSTEM для Ktm LC4 400 Dual Sport - 2000 года выпуска
-
№АртикулНазвание
-
158405026000 SEKONDARY AIRVALVESEKONDARY AIRVALVE
-
258405024000 CONTROL VALVE ASVCONTROL VALVE ASV
-
358436039000 EXHAUST FLANGE CPL. (FOR SLS)EXHAUST FLANGE CPL. (FOR SLS)
-
458405027000 CONNECTING TUBE SLSCONNECTING TUBE SLS
-
658436054000 CU-SEAL RING 12 X 16 X 2CU-SEAL RING 12 X 16 X 2
-
858405023000 HEXAGON NUT M16X1,5HEXAGON NUT M16X1,5
-
1058335025001 RADIATOR HOSE (REENFORCED) 12X3RADIATOR HOSE (REENFORCED) 12X3
-
1158405028000 PREFORMED HOSE 18X3,5PREFORMED HOSE 18X3,5
-
1258405029001 ND-HOSE 4X9 PER METERND-HOSE 4X9 PER METER
-
1458405025000 BRACKET FOR CONTROL VALVEBRACKET FOR CONTROL VALVE
-
1500050250906 WV-CLAMP D=25MM OETIKERWV-CLAMP D=25MM OETIKER
-
1658335099000 HOSE CLAMP GEMI 10-16HOSE CLAMP GEMI 10-16
-
1710001020000 HOSE CLAMP GEMI 16/27HOSE CLAMP GEMI 16/27
-
180912060404 AH SCREW DIN0912-M 6X40AH SCREW DIN0912-M 6X40
-
1956509064100 SELF LOCKING NUT M6 10.9SELF LOCKING NUT M6 10.9
-
3658336020090 VACUUM CONNECTION M6X1VACUUM CONNECTION M6X1
