FOOTRESTS для Kawasaki Super Sherpa - 2000 года выпуска

  • №
    Артикул
    Название
  • 132
    132J0820 BOLT, FLANGED, SMALL
    BOLT, FLANGED, SMALL
  • 550
    550D2015 PIN, COTTER, 2.0X15
    PIN, COTTER, 2.0X15
  • 550A
    550D2018 PIN, COTTER, 2.0X18
    PIN, COTTER, 2.0X18
  • 34003
    34003-1460-EZ HOLDER, STEP, REAR (LEFT) (C.GRAY)
    HOLDER, STEP, REAR (LEFT) (C.GRAY)
  • 34003A
    34003-1461-EZ HOLDER, STEP, REAR (RIGHT) (C.GRAY)
    HOLDER, STEP, REAR (RIGHT) (C.GRAY)
  • 34028
    34028-009 STEP, REAR
    STEP, REAR
  • 34028A
    34028-1431 STEP, FRONT (LEFT)
    STEP, FRONT (LEFT)
  • 34028B
    34028-1432 STEP, FRONT (RIGHT)
    STEP, FRONT (RIGHT)
  • 92022
    92022-1568 WASHER, 20X30X2.3
    WASHER, 20X30X2.3
  • 92022A
    92022-239 WASHER, 10.5X20X1
    WASHER, 10.5X20X1
  • 92043
    92043-1217 PIN, 10X35
    PIN, 10X35
  • 92043A
    92043-1464 PIN, 6X28
    PIN, 6X28
  • 92076
    92076-020 DAMPER
    DAMPER
  • 92081
    92081-1606 SPRING, STEP (LEFT)
    SPRING, STEP (LEFT)
  • 92081A
    92081-1607 SPRING, STEP (RIGHT)
    SPRING, STEP (RIGHT)
