07- Steering System для BRP Ski-Doo Summit X 800 HO - 2003

  • №
    Артикул
    Название
  • 1
    515175830 Low temperature tubing 1/2''
    Low temperature tubing 1/2''
  • 2
    414115200 Tie rap 180 mm
    Tie rap 180 mm
  • 3
    293750002 Locking Tie 142 mm
    Locking Tie 142 mm
  • 4
    515175977 Handle harness. Includes 4 - 17.
    Handle harness. Includes 4 - 17.
  • 5
    515175232 Male terminal
    Male terminal
  • 6
    515175273 Male terminal
    Male terminal
  • 7
    515175231 Female terminal
    Female terminal
  • 8
    515175352 Male terminal housing (13 circuits)
    Male terminal housing (13 circuits)
  • 9
    415079900 Tubing 10 mm
    Tubing 10 mm
  • 10
    515175543 Female terminal housing (6 circuits)
    Female terminal housing (6 circuits)
  • 11
    515175808 Female terminal
    Female terminal
  • 12
    515175809 Female lock (8 circuits)
    Female lock (8 circuits)
  • 13
    515175807 Female terminal housing (8 circuits). (black)
    Female terminal housing (8 circuits). (black)
  • 14
    515175810 Female terminal housing (8 circuits). (gray)
    Female terminal housing (8 circuits). (gray)
  • 15
    515175819 Female terminal housing (8 circuits)
    Female terminal housing (8 circuits)
  • 16
    515175830 Tubing
    Tubing
  • 17
    515175941 Female terminal
    Female terminal
  • 18
    515175662 Male terminal housing (6 circuits)
    Male terminal housing (6 circuits)
  • 19
    515175817 Male terminal housing (8 circuits)
    Male terminal housing (8 circuits)
  • 20
    515175944 Housing support
    Housing support
  • 21
    515175232 Male terminal
    Male terminal
  • 22
    515175772 Switch housing
    Switch housing
  • 515175789 Switch housing (RER)
    Switch housing (RER)
  • 23
    515175926 Switch housing plate
    Switch housing plate
  • 24
    250000100 Screw #8-18
    Screw #8-18
  • 25
    271000110 Protection trim
    Protection trim
