09- Body And Accessories 2 для BRP DS 650/DS 650 X - 2005
-
№АртикулНазвание
-
1705000301 RH Foot ProtectorRH Foot Protector
-
1705000302 LH Foot ProtectorLH Foot Protector
-
2705000639 RH Foot Protector SupportRH Foot Protector Support
-
2705000642 LH Foot Protector SupportLH Foot Protector Support
-
3705000117 RH SupportRH Support
-
3705000120 LH SupportLH Support
-
4293650150 Gear ClampGear Clamp
-
5211000123 Truss Phillips Screw M6 X 20Truss Phillips Screw M6 X 20
-
6250000032 Screw M6 X 30Screw M6 X 30
-
7232561414 Elastic Stop Nut M6Elastic Stop Nut M6
-
8207662544 Hex Flanged Screw M6 X25Hex Flanged Screw M6 X25
-
9224061201 Flat WasherFlat Washer
-
10233261414 Hex Flanged Elastic Nut M6Hex Flanged Elastic Nut M6
-
11703500125 Rear Fender Kit (black). DS 650 X / Includes 11 to 13Rear Fender Kit (black). DS 650 X / Includes 11 to 13
-
11703500471 Rear Fender Kit (red). DS 650 / Includes 11 to 13Rear Fender Kit (red). DS 650 / Includes 11 to 13
-
12704900040 Warning Label Ass'y (english, Passenger)Warning Label Ass'y (english, Passenger)
-
13704900102 Warning LabelWarning Label
-
14207161844 Hex Screw M6 X 18Hex Screw M6 X 18
-
15224061201 Flat WasherFlat Washer
-
16233261414 Hex Flanged Elastic Nut M6Hex Flanged Elastic Nut M6
-
17710000711 Tail Light Housing Ass'y. Includes 17 to 20Tail Light Housing Ass'y. Includes 17 to 20
-
18710000055 Tail Light LensTail Light Lens
-
19410504100 Tail Light BulbTail Light Bulb
-
20710000129 GasketGasket
-
21208657041 Phillips Screw M5 X 70Phillips Screw M5 X 70
-
22517245900 BushingBushing
-
23414036300 GrommetGrommet
-
24233251414 Hex Flanged Elastic Nut M5Hex Flanged Elastic Nut M5
-
25224060201 Flat WasherFlat Washer
-
26705000143 Rear BumperRear Bumper
-
27207682044 Hex Flanged Screw M8 X 20Hex Flanged Screw M8 X 20
-
28233281414 Hex Flanged Elastic Nut M8Hex Flanged Elastic Nut M8
-
29705000304 Skid Plate. DS 650Skid Plate. DS 650
-
30207662044 Hex. Flanged Screw M6 X 20. DS 650Hex. Flanged Screw M6 X 20. DS 650
-
31233261414 Hex Flanged Elastic Nut M6. DS 650Hex Flanged Elastic Nut M6. DS 650
