WINDSHIELD AND INSTRUMENTS ASSEMBLIES для Arctic Cat ZR 7000 129 LTD GREEN [S2016ZRULEUSG] - 2016 года выпуска

  • №
    Артикул
    Название
  • 1
    4718-697 POD W/DECALS - GREEN (INC. 2-3)
    POD W/DECALS - GREEN (INC. 2-3)
  • 2
    6606-693 ...POD, INSTRUMENT - GREEN
    ...POD, INSTRUMENT - GREEN
  • 3
    2621-378 ...DECAL, POD - RIGHT - GREEN
    ...DECAL, POD - RIGHT - GREEN
  • 3
    2621-379 ...DECAL, POD - LEFT - GREEN
    ...DECAL, POD - LEFT - GREEN
  • 4
    0641-897 OUTLET, ACCESSORY - 12V
    OUTLET, ACCESSORY - 12V
  • 5
    1623-129 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 6
    6606-566 BAG, GOGGLE
    BAG, GOGGLE
  • 7
    0609-911 SWITCH, IGNITION (INC. 8-10)
    SWITCH, IGNITION (INC. 8-10)
  • 8
    0430-050 ...NUT, RETAINING
    ...NUT, RETAINING
  • 9
    0430-042 ...KEY, IGNITION Y SERIES - LEFT-SIDE CUT
    ...KEY, IGNITION Y SERIES - LEFT-SIDE CUT
  • 9
    0430-043 ...KEY, IGNITION Z SERIES - RIGHT-SIDE CUT
    ...KEY, IGNITION Z SERIES - RIGHT-SIDE CUT
  • 10
    0430-054 ...COVER, KEY
    ...COVER, KEY
  • 11
    0720-029 GAUGE, SPEEDOMETER
    GAUGE, SPEEDOMETER
  • 12
    2623-042 SCREW, SHOULDER
    SCREW, SHOULDER
  • 13
    1623-025 INSERT
    INSERT
  • 14
    7606-065 WINDSHIELD - MID - GREEN
    WINDSHIELD - MID - GREEN
  • 15
    2623-017 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
