SUSPENSION REAR - REAR ARM SHOCK ABSORBER для Arctic Cat ZR 7000 SNO PRO RR EARLY BUILD (GREEN) [S2015ZRURRUSG] - 2015 года выпуска

  • №
    Артикул
    Название
  • -
    2704-634 SHOCK ABSORBER
    SHOCK ABSORBER
  • 1
    4604-024 EYELET, SHOCK - ASSEMBLY (INC. 2-6)
    EYELET, SHOCK - ASSEMBLY (INC. 2-6)
  • 2
    4604-077 ...SPACER
    ...SPACER
  • 3
    3603-399 ...BEARING
    ...BEARING
  • 4
    4604-076 ...SLEEVE
    ...SLEEVE
  • 5
    4604-027 ...KIT, REBUILD - SHOCK
    ...KIT, REBUILD - SHOCK
  • 6
    4604-022 ...KNOB, DAMPING - EYELET
    ...KNOB, DAMPING - EYELET
  • 7
    4604-025 SHAFT, SHOCK
    SHAFT, SHOCK
  • 8
    4604-023 ROD, DAMPING ADJUSTER - ASSEMBLY
    ROD, DAMPING ADJUSTER - ASSEMBLY
  • 9
    2604-953 NEEDLE, DAMPING W/O-RING
    NEEDLE, DAMPING W/O-RING
  • 10
    4604-029 VALVE, CHECK - ASSEMBLY
    VALVE, CHECK - ASSEMBLY
  • 11
    4604-020 CAP, BEARING
    CAP, BEARING
  • 12
    0604-992 RING, RETAINING
    RING, RETAINING
  • 13
    4604-021 BODY, SHOCK
    BODY, SHOCK
  • 14
    3603-418 DECAL, WARNING
    DECAL, WARNING
  • 15
    4604-026 SPACER
    SPACER
  • 16
    2604-449 WASHER, TOP OUT
    WASHER, TOP OUT
  • 17
    2604-480 VALVE, (0.950 X 0.010 IN.)
    VALVE, (0.950 X 0.010 IN.)
  • 18
    2604-485 VALVE, (1.100 X 0.008 IN.)
    VALVE, (1.100 X 0.008 IN.)
  • 19
    2604-491 VALVE, (1.350 X 0.008 IN.)
    VALVE, (1.350 X 0.008 IN.)
  • 20
    2604-496 VALVE, (1.425 X 0.008 IN.)
    VALVE, (1.425 X 0.008 IN.)
  • 21
    2604-501 VALVE, (1.600 X 0.008 IN.)
    VALVE, (1.600 X 0.008 IN.)
  • 22
    2604-486 VALVE, (1.100 X 0.010 IN.)
    VALVE, (1.100 X 0.010 IN.)
  • 23
    2604-502 VALVE, (1.600 X 0.010 IN.)
    VALVE, (1.600 X 0.010 IN.)
  • 24
    2604-693 VALVE, RING - (1.600 X 0.015 IN.)
    VALVE, RING - (1.600 X 0.015 IN.)
  • 25
    2604-498 VALVE, (1.425 X 0.012 IN.)
    VALVE, (1.425 X 0.012 IN.)
  • 26
    3603-410 VALVE, BLEED - (1.600 X 0.006 IN.)
    VALVE, BLEED - (1.600 X 0.006 IN.)
  • 27
    0403-394 PISTON, HIGH-FLOW - (1.834 IN.) BORE
    PISTON, HIGH-FLOW - (1.834 IN.) BORE
  • 28
    2604-497 VALVE, (1.425 X 0.010 IN.)
    VALVE, (1.425 X 0.010 IN.)
  • 29
    4604-036 VALVE, (1.150 X 0.004 IN.)
    VALVE, (1.150 X 0.004 IN.)
  • 30
    3604-610 WASHER, TOP OUT
    WASHER, TOP OUT
  • 31
    3604-184 WASHER, BACKUP
    WASHER, BACKUP
  • 32
    3603-407 END CAP, BODY/RESERVOIR
    END CAP, BODY/RESERVOIR
  • 33
    4604-017 KIT, REBUILD - RESERVOIR
    KIT, REBUILD - RESERVOIR
  • 34
    3603-379 RING, RETAINING
    RING, RETAINING
  • 35
    3604-422 BODY, SHOCK
    BODY, SHOCK
  • 36
    3603-388 RESERVOIR
    RESERVOIR
  • 37
    3603-365 DECAL, "PERFORMANCE SERIES"
    DECAL, "PERFORMANCE SERIES"
  • 38
    3603-378 DECAL, RESERVOIR
    DECAL, RESERVOIR
  • 39
    4604-019 PISTON, CONCENTRIC - DAMPING ADJUSTER
    PISTON, CONCENTRIC - DAMPING ADJUSTER
  • 40
    3603-385 KNOB, DAMPING ADJUSTER - LOW SPEED
    KNOB, DAMPING ADJUSTER - LOW SPEED
  • 41
    3603-377 SCREW, MACHINE
    SCREW, MACHINE
  • 42
    5639-530 OIL, SHOCK - (1 QT)
    OIL, SHOCK - (1 QT)
