CRANKCASE ASSEMBLY для Arctic Cat ZR 6000 RXC (GREEN) [S2015ACDCCUSG] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    1901-001 CRANKCASE - 600 - MFG ASSEMBY (INC. 2-3)
    CRANKCASE - 600 - MFG ASSEMBY (INC. 2-3)
  • 2
    0901-013 ...PLUG, CASE
    ...PLUG, CASE
  • 3
    0901-004 ...BUSHING,OIL PUMP INPUT SHAFT
    ...BUSHING,OIL PUMP INPUT SHAFT
  • 4
    0929-003 PIN, DOWEL
    PIN, DOWEL
  • 5
    0923-034 SCREW,CAP-HFH M10X1.25X90 CL 10.9
    SCREW,CAP-HFH M10X1.25X90 CL 10.9
  • 6
    0923-022 SCREW,CAP-HFH M8X1X88 CL8.8
    SCREW,CAP-HFH M8X1X88 CL8.8
  • 7
    0923-012 SCREW,CAP-HFH M8X1.25X50 CL10.9
    SCREW,CAP-HFH M8X1.25X50 CL10.9
  • 8
    0923-026 SCREW,CAP-TSRDWH M6X1X25 CL 10.9
    SCREW,CAP-TSRDWH M6X1X25 CL 10.9
  • 9
    0829-002 PIN, DOWEL
    PIN, DOWEL
  • 10
    0923-013 STUD, M10 X 66.5-CYLINDER
    STUD, M10 X 66.5-CYLINDER
  • 11
    0923-057 GASKET - COPPER
    GASKET - COPPER
  • 12
    0902-010 SENSOR, ENGINE COOLANT TEMPERATURE
    SENSOR, ENGINE COOLANT TEMPERATURE
  • 13
    0923-040 TIE, CABLE - 7.6 IN.
    TIE, CABLE - 7.6 IN.
  • 14
    0830-155 SEAL,FASTENER
    SEAL,FASTENER
  • 15
    8468-613 SCREW,MACH-TSPNH M6X1.0X12 CL8.8 W/2343
    SCREW,MACH-TSPNH M6X1.0X12 CL8.8 W/2343
