SEAT ASSEMBLY для Arctic Cat PANTERA 7000 (BLACK) - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    5706-853 COMPLETE SEAT ASSEMBLY - (BLACK) (INC. 2-11)
    COMPLETE SEAT ASSEMBLY - (BLACK) (INC. 2-11)
  • 2
    5706-852 ...COVER, SEAT - (BLACK) (INC. 3)
    ...COVER, SEAT - (BLACK) (INC. 3)
  • 3
    3606-369 ......WIRE,SEAT-BENT
    ......WIRE,SEAT-BENT
  • 4
    0717-220 ...FOAM,SEAT-FRONT-TOUR-(.40R @ 5.0)
    ...FOAM,SEAT-FRONT-TOUR-(.40R @ 5.0)
  • 5
    0609-913 ...PAD, SEAT HEATER
    ...PAD, SEAT HEATER
  • 6
    6606-461 ...WIRE,SEAT-3.048 DIA X 279.4 MM
    ...WIRE,SEAT-3.048 DIA X 279.4 MM
  • 7
    0624-528 ...STAPLE,5/16L X 1/2W-20GA SS/5000 PAK-SEA
    ...STAPLE,5/16L X 1/2W-20GA SS/5000 PAK-SEA
  • 8
    5706-856 ...BASE,SEAT W/CLIP (INC. 9-11)
    ...BASE,SEAT W/CLIP (INC. 9-11)
  • 9
    6606-879 ......LATCH, SEAT
    ......LATCH, SEAT
  • 10
    1623-997 ......CLIP,RETAINING SPRING-SEAT
    ......CLIP,RETAINING SPRING-SEAT
  • 11
    8061-706 ......RIVET,BLIND-LF SS64 (BLACK)
    ......RIVET,BLIND-LF SS64 (BLACK)
