REED VALVE ASSEMBLY для Arctic Cat M 8000 SNO PRO LTD ES 162 (GREEN) [S2015M8HELUSG] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    3007-886 VALVE, REED - ASSEMBLY (INC. 2-4)
    VALVE, REED - ASSEMBLY (INC. 2-4)
  • 2
    3007-887 ...STOPPER,REED VALVE
    ...STOPPER,REED VALVE
  • 3
    3007-888 ...VALVE, REED
    ...VALVE, REED
  • 4
    3004-506 ...SCREW, 3X8
    ...SCREW, 3X8
  • 5
    3005-879 GASKET, REED VALVE
    GASKET, REED VALVE
  • 6
    3006-527 PIPE,INTAKE
    PIPE,INTAKE
  • 7
    3402-455 CLAMP, DUCT REAR
    CLAMP, DUCT REAR
  • 8
    3007-380 BOLT
    BOLT
  • 9
    1623-984 CLAMP, WIRE - 76.14MM LG W/6.25 HOLE (OPTIONAL)
    CLAMP, WIRE - 76.14MM LG W/6.25 HOLE (OPTIONAL)
