PISTON AND CRANKSHAFT для Arctic Cat M 8000 SNO PRO LTD ES 162 (GREEN) [S2015M8HELUSG] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    3007-877 PISTON SET (INC. 2-3)
    PISTON SET (INC. 2-3)
  • 2
    3006-394 ...RING SET, PISTON
    ...RING SET, PISTON
  • 3
    3005-304 ...CIRCLIP, PISTON
    ...CIRCLIP, PISTON
  • 4
    3007-878 PIN, PISTON
    PIN, PISTON
  • 5
    3008-500 WASHER,22MM
    WASHER,22MM
  • 6
    3008-503 BEARING,NEEDLE,M22
    BEARING,NEEDLE,M22
  • 7
    3007-879 CRANKSHAFT ASSEMBLY (INC. 8-24)
    CRANKSHAFT ASSEMBLY (INC. 8-24)
  • 8
    3007-880 ...CONNECTING ROD
    ...CONNECTING ROD
  • 9
    3007-881 ...CRANKSHAFT - RIGHT
    ...CRANKSHAFT - RIGHT
  • 10
    3007-882 ...CRANKSHAFT - MIDDLE
    ...CRANKSHAFT - MIDDLE
  • 11
    3007-883 ...WHEEL, CRANKSHAFT
    ...WHEEL, CRANKSHAFT
  • 12
    3007-884 ...CRANKSHAFT - LEFT
    ...CRANKSHAFT - LEFT
  • 13
    3007-667 ...BALANCER, CRANKSHAFT
    ...BALANCER, CRANKSHAFT
  • 14
    3006-508 ...RACE, MIDDLE CRANK SEAL
    ...RACE, MIDDLE CRANK SEAL
  • 15
    3005-508 ...RING, MIDDLE CRANK SEAL
    ...RING, MIDDLE CRANK SEAL
  • 16
    3007-885 ...GEAR, OIL PUMP DRIVE
    ...GEAR, OIL PUMP DRIVE
  • 17
    3004-147 ...WASHER
    ...WASHER
  • 18
    3006-489 ...SHIM,30X38X1
    ...SHIM,30X38X1
  • 19
    3008-495 ...WASHER,40MM
    ...WASHER,40MM
  • 20
    3008-421 ...BEARING,BALL,M35
    ...BEARING,BALL,M35
  • 21
    3007-532 ...BEARING,CRANK PIN
    ...BEARING,CRANK PIN
  • 22
    3007-439 ...BEARING-LH
    ...BEARING-LH
  • 23
    3006-551 ...BEARING - RIGHT
    ...BEARING - RIGHT
  • 24
    3007-440 ...SCREW
    ...SCREW
  • 25
    3007-533 SEAL, OIL
    SEAL, OIL
  • 26
    3003-759 SEAL, OIL - LEFT
    SEAL, OIL - LEFT
  • 27
    3003-359 C-RING,CRANKSHAFT,M75
    C-RING,CRANKSHAFT,M75
  • 28
    3003-658 PIN,ALIGNMENT
    PIN,ALIGNMENT
  • 29
    3006-552 SPACER,OIL SEAL
    SPACER,OIL SEAL
