WATER PUMP AND THERMOSTAT для Arctic Cat M 8000 HCR 153 (GREEN) [S2015M8HHCUSG] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    3007-540 COVER, WATER PUMP
    COVER, WATER PUMP
  • 2
    3007-541 O RING,WATER PUMP COVER
    O RING,WATER PUMP COVER
  • 3
    3007-180 SEAL,MECHANICAL
    SEAL,MECHANICAL
  • 4
    3007-896 IMPELLER,WATER PUMP
    IMPELLER,WATER PUMP
  • 5
    3003-426 BOLT, SHAFT
    BOLT, SHAFT
  • 6
    3003-431 WASHER, SHAFT
    WASHER, SHAFT
  • 7
    3003-432 WASHER,6MM
    WASHER,6MM
  • 8
    3007-542 HOSE, WATER INLET
    HOSE, WATER INLET
  • 9
    3007-431 OIL SEAL-10X22X6
    OIL SEAL-10X22X6
  • 10
    3004-786 CLAMP,M38
    CLAMP,M38
  • 11
    3007-409 BOLT
    BOLT
  • 12
    3005-899 PIN, DOWEL
    PIN, DOWEL
  • 13
    3007-714 CIRCLIP,BEARING FASTENER
    CIRCLIP,BEARING FASTENER
  • 14
    3007-041 THERMOSTAT,WATER
    THERMOSTAT,WATER
  • 15
    3007-304 HOUSING, THERMOSTAT
    HOUSING, THERMOSTAT
  • 16
    3007-543 GASKET,THERMOSTAT CAP
    GASKET,THERMOSTAT CAP
  • 17
    3007-446 BOLT,THERMOSTAT CAP
    BOLT,THERMOSTAT CAP
  • 18
    3007-306 BOLT,THERMOSTAT CAP (6X18.4)
    BOLT,THERMOSTAT CAP (6X18.4)
