SEAT ASSEMBLY для Arctic Cat F8 LXR (ORANGE) - 2011 года выпуска

  • №
    Артикул
    Название
  • -
    5706-031 COMPLETE SEAT ASSEMBLY - GREEN
    COMPLETE SEAT ASSEMBLY - GREEN
  • 1
    5706-032 COVER, SEAT - GREEN
    COVER, SEAT - GREEN
  • 2
    0617-570 FOAM, SEAT
    FOAM, SEAT
  • 3
    0624-528 STAPLE
    STAPLE
  • 4
    5706-010 SEAT-BASE - ASSEMBLY (INC. 5-16)
    SEAT-BASE - ASSEMBLY (INC. 5-16)
  • 5
    5606-591 ...SEAT-BASE
    ...SEAT-BASE
  • 6
    8061-688 ...RIVET
    ...RIVET
  • 7
    1623-524 ...WASHER, SLIDE PIN - BOTTOM
    ...WASHER, SLIDE PIN - BOTTOM
  • 8
    3706-886 ...FRAME, SEAT
    ...FRAME, SEAT
  • 9
    4606-338 ...PIN, SLIDE - BOTTOM
    ...PIN, SLIDE - BOTTOM
  • 10
    1623-130 ...RIVET
    ...RIVET
  • 11
    1623-525 ...WASHER, SLIDE PIN - TOP
    ...WASHER, SLIDE PIN - TOP
  • 12
    4606-339 ...PIN, SLIDE - TOP
    ...PIN, SLIDE - TOP
  • 13
    1623-542 ...NUT, SLIDE PIN
    ...NUT, SLIDE PIN
  • 14
    0123-788 ...TIE, CABLE - 8 IN.
    ...TIE, CABLE - 8 IN.
  • 15
    5606-592 ...CABLE, SEAT ADJUSTER
    ...CABLE, SEAT ADJUSTER
  • 16
    4606-380 ...LEVER, SEAT ADJUSTER CABLE
    ...LEVER, SEAT ADJUSTER CABLE
  • 17
    4606-345 HOUSING, CABLE - SEAT ADJUSTER
    HOUSING, CABLE - SEAT ADJUSTER
  • 18
    1623-609 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 19
    4706-886 KIT, TOOL
    KIT, TOOL
