SHOCK ABSORBER AND SWAY BAR ASSEMBLY для Arctic Cat CFR 800 - 2011 года выпуска

  • №
    Артикул
    Название
  • 1
    2703-514 SHOCK, SKI-18.72" ZERO PRO
    SHOCK, SKI-18.72" ZERO PRO
  • 2
    3604-200 RETAINER, SPRING-POWDER METAL
    RETAINER, SPRING-POWDER METAL
  • 3
    8047-486 NUT, LOCK
    NUT, LOCK
  • 4
    3604-594 SLEEVE, SHOCK
    SLEEVE, SHOCK
  • 5
    0623-991 WASHER, FLAT ALUM-.390 X 1.125 X .125
    WASHER, FLAT ALUM-.390 X 1.125 X .125
  • 6
    8020-232 SCREW, CAP
    SCREW, CAP
  • 7
    2603-493 SPACER, SHOCK MOUNT
    SPACER, SHOCK MOUNT
  • 8
    2703-016 SPRING, COMPRESSION - GREEN
    SPRING, COMPRESSION - GREEN
  • 9
    2703-094 SWAY BAR, 7/16 DIA X 21.21"-PTD BLK
    SWAY BAR, 7/16 DIA X 21.21"-PTD BLK
  • 10
    2603-648 BEARING, SWAY BAR-HIGH TEMP
    BEARING, SWAY BAR-HIGH TEMP
  • 11
    2703-096 ARM, SWAY BAR
    ARM, SWAY BAR
  • 12
    8020-045 SCREW, CAP
    SCREW, CAP
  • 13
    8047-366 NUT, LOCK
    NUT, LOCK
  • 14
    2603-649 LINK, SWAY BAR
    LINK, SWAY BAR
  • 15
    8047-426 NUT, LOCK
    NUT, LOCK
  • 16
    1623-584 BOLT, CARRIAGE
    BOLT, CARRIAGE
