DRIVEN CLUTCH для Arctic Cat CFR 800 - 2011 года выпуска

  • №
    Артикул
    Название
  • -
    0726-308 CLUTCH, DRIVEN-10.4(44/40N/ORN)-W/PLATES
    CLUTCH, DRIVEN-10.4(44/40N/ORN)-W/PLATES
  • 1
    0748-714 CAM, DRIVEN-44/40 DEG (N) W/BRG-ASSY...(INC. 2-3)
    CAM, DRIVEN-44/40 DEG (N) W/BRG-ASSY...(INC. 2-3)
  • 1
    0748-700 CAM, DRIVEN-36 DEG (N) W/BRG-ASSY...(INC. 2-3) - OVER 3,000 FT ALT.
    CAM, DRIVEN-36 DEG (N) W/BRG-ASSY...(INC. 2-3) - OVER 3,000 FT ALT.
  • 2
    0648-433 ...RING, SNAP
    ...RING, SNAP
  • 3
    0648-009 ...BEARING, DRIVEN CLUTCH 24DU08
    ...BEARING, DRIVEN CLUTCH 24DU08
  • 4
    0648-713 SEAT, SPRING
    SEAT, SPRING
  • 5
    0648-774 SPRING, DRIVEN-175-280-ORANGE
    SPRING, DRIVEN-175-280-ORANGE
  • 6
    0648-806 SPACER
    SPACER
  • 7
    0648-453 SEAT, SPRING
    SEAT, SPRING
  • 8
    0648-097 PIN, CAM ROLLER
    PIN, CAM ROLLER
  • 9
    0648-139 ROLLER, CAM
    ROLLER, CAM
  • 10
    8070-224 PIN, SPRING
    PIN, SPRING
  • 11
    0637-322 RETAINER, TORQUE BRACKET (INC. 12)
    RETAINER, TORQUE BRACKET (INC. 12)
  • 12
    1623-517 ...SCREW, MACHINE
    ...SCREW, MACHINE
  • 13
    0623-914 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 14
    0648-728 COVER
    COVER
