SEAT ASSEMBLY для Arctic Cat CFR 800 - 2011 года выпуска

  • №
    Артикул
    Название
  • 1
    4706-955 COMPLETE SEAT ASSEMBLY (INC. 2-8)
    COMPLETE SEAT ASSEMBLY (INC. 2-8)
  • 2
    4706-929 ...COVER, SEAT
    ...COVER, SEAT
  • 3
    3706-118 ...FOAM, SEAT CUSHION
    ...FOAM, SEAT CUSHION
  • 4
    0624-528 ...STAPLE
    ...STAPLE
  • 5
    4606-128 ...SEAT-BASE
    ...SEAT-BASE
  • 6
    1623-393 ...CLIP, RETAINING
    ...CLIP, RETAINING
  • 7
    0123-788 ...TIE, CABLE - 8 IN.
    ...TIE, CABLE - 8 IN.
  • 8
    0617-512 ...FOAM, COMPARTMENT
    ...FOAM, COMPARTMENT
  • 9
    8047-426 NUT, LOCK
    NUT, LOCK
  • 10
    1623-458 STUD, LATCH
    STUD, LATCH
  • 11
    4606-322 COVER, LATCH - RIGHT
    COVER, LATCH - RIGHT
  • 12
    8061-628 RIVET
    RIVET
  • 13
    3706-033 RETAINER, TOOL KIT
    RETAINER, TOOL KIT
  • 14
    4706-886 KIT, TOOL
    KIT, TOOL
