REAR SUSPENSION REAR ARM SHOCK ABSORBER для Arctic Cat CFR 800 - 2011 года выпуска`
-
№АртикулНазвание
-
-1704-807 COMPLETE SHOCK ABSORBERCOMPLETE SHOCK ABSORBER
-
11604-222 BUSHING, SHOCKBUSHING, SHOCK
-
22604-223 SLEEVE, EYELETSLEEVE, EYELET
-
30604-893 EYELET, SHOCKEYELET, SHOCK
-
42604-863 ROD, SHOCKROD, SHOCK
-
52604-413 CAP, SHOCKCAP, SHOCK
-
62604-815 KIT, SEAL/REBUILDKIT, SEAL/REBUILD
-
70603-540 WASHER, TOP OUTWASHER, TOP OUT
-
80603-333 VALVE, 0.800 X 0.006 IN.VALVE, 0.800 X 0.006 IN.
-
90603-338 VALVE, 0.900 X 0.010 IN.VALVE, 0.900 X 0.010 IN.
-
100603-341 VALVE, 1.000 X 0.010 IN.VALVE, 1.000 X 0.010 IN.
-
110603-888 VALVE, 1.100 X 0.015 IN.VALVE, 1.100 X 0.015 IN.
-
120603-347 VALVE, 1.250 X 0.010 IN.VALVE, 1.250 X 0.010 IN.
-
130603-336 VALVE, 0.900 X 0.006 IN.VALVE, 0.900 X 0.006 IN.
-
140603-344 VALVE, 1.100 X 0.010 IN.VALVE, 1.100 X 0.010 IN.
-
150603-350 VALVE, 1.300 X 0.010 IN.VALVE, 1.300 X 0.010 IN.
-
162603-482 PISTON, 0.046 IN. - ORIFICEPISTON, 0.046 IN. - ORIFICE
-
170603-335 VALVE, 0.800 X 0.010 IN.VALVE, 0.800 X 0.010 IN.
-
180603-389 WASHER, BACKUPWASHER, BACKUP
-
190603-301 NUTNUT
-
202604-816 PISTON, FLOATINGPISTON, FLOATING
-
211604-316 SCREW, MACHINE W/O-RING (INC. 22)SCREW, MACHINE W/O-RING (INC. 22)
-
221604-425 ...O-RING...O-RING
-
232604-897 DECAL, SHOCKDECAL, SHOCK
-
242604-864 BODY, SHOCKBODY, SHOCK
-
252604-817 END CAP, SHOCK - ASSEMBLY (INC. 26-27)END CAP, SHOCK - ASSEMBLY (INC. 26-27)
-
260703-341 ...VALVE, PRESSURE - ASSEMBLY (INC. 27)...VALVE, PRESSURE - ASSEMBLY (INC. 27)
-
271604-318 ......O-RING......O-RING
-
280624-097 SCREW, VALVESCREW, VALVE
-
295639-240 SEMI-SYN SHOCK OIL-1 QUARTSEMI-SYN SHOCK OIL-1 QUART
