CYLINDER AND CRANKCASE для Arctic Cat 120 SNO PRO - 2009 года выпуска

  • №
    Артикул
    Название
  • 1
    0693-362 HOSE, AIR BREATHER
    HOSE, AIR BREATHER
  • 2
    0693-241 SCREW, CAP
    SCREW, CAP
  • 3
    0691-830 COVER, CYLINDER HEAD
    COVER, CYLINDER HEAD
  • 4
    0691-393 BODY, AIR BREATHER - ASSEMBLY (INC. 5-6)
    BODY, AIR BREATHER - ASSEMBLY (INC. 5-6)
  • 5
    0693-226 ...VALVE, REED - SET
    ...VALVE, REED - SET
  • 6
    0693-305 ...SCREW, MACHINE
    ...SCREW, MACHINE
  • 7
    0691-387 GASKET, CYLINDER HEAD COVER
    GASKET, CYLINDER HEAD COVER
  • 8
    3004-326 NUT,INTER COOLER
    NUT,INTER COOLER
  • 9
    0691-852 GASKET, EXHAUST
    GASKET, EXHAUST
  • 10
    0693-317 STUD BOLT,M8X16
    STUD BOLT,M8X16
  • 11
    0693-303 BOLT,INLET PIPE
    BOLT,INLET PIPE
  • 12
    0691-386 GASKET, CYLINDER HEAD
    GASKET, CYLINDER HEAD
  • 13
    0694-034 HEAD, CYLINDER (INC. 14)
    HEAD, CYLINDER (INC. 14)
  • 14
    0691-545 ...GUIDE, VALVE
    ...GUIDE, VALVE
  • 15
    0217-703 PLUG, SPARK (BPR6ES)
    PLUG, SPARK (BPR6ES)
  • 16
    0693-307 SCREW, CAP
    SCREW, CAP
  • 17
    0694-022 COVER, OIL LEVEL SENSOR
    COVER, OIL LEVEL SENSOR
  • 18
    0691-837 GASKET, ENGINE OIL LEVEL SENSOR
    GASKET, ENGINE OIL LEVEL SENSOR
  • 19
    0694-001 CYLINDER ASSEMBLY (INC. 20-21 AND ONE NO. 22-23)
    CYLINDER ASSEMBLY (INC. 20-21 AND ONE NO. 22-23)
  • 20
    0693-253 ...PLUG
    ...PLUG
  • 21
    3002-276 ...GASKET
    ...GASKET
  • 22
    0691-374 ...BEARING
    ...BEARING
  • 23
    0691-376 ...SEAL, OIL
    ...SEAL, OIL
  • 24
    3005-206 PIN, DOWEL
    PIN, DOWEL
  • 25
    3008-199 PIN, DOWEL
    PIN, DOWEL
  • 26
    0694-002 COVER, CRANKCASE - ASSEMBLY - SIDE (INC. ONE NO. 22-23 AND 27)
    COVER, CRANKCASE - ASSEMBLY - SIDE (INC. ONE NO. 22-23 AND 27)
  • 27
    0691-844 ...SHAFT, GOVERNOR GEAR
    ...SHAFT, GOVERNOR GEAR
  • 28
    0691-834 GASKET, CRANKCASE
    GASKET, CRANKCASE
  • 29
    0694-035 SCREW, CAP
    SCREW, CAP
  • 30
    0694-004 PLUG, ENGINE OIL DRAIN - ASSEMBLY (INC. ONE NO. 31)
    PLUG, ENGINE OIL DRAIN - ASSEMBLY (INC. ONE NO. 31)
  • 31
    0693-298 ...O-RING
    ...O-RING
  • 32
    0694-003 STICK, OIL LEVEL (INC. ONE NO. 31)
    STICK, OIL LEVEL (INC. ONE NO. 31)
