BATTERY- SOLENOID- AND CABLES для Arctic Cat Z 370 (ORANGE LX) - 2007 года выпуска

  • №
    Артикул
    Название
  • 1
    0745-045 BATTERY (INC. 2-6)
    BATTERY (INC. 2-6)
  • 2
    0645-045 ...CAP, BATTERY
    ...CAP, BATTERY
  • 3
    0645-152 ...CLAMP, HOSE
    ...CLAMP, HOSE
  • 4
    0645-263 ...HOSE, BATTERY VENT
    ...HOSE, BATTERY VENT
  • 5
    0645-151 ...DECAL, WARNING - BATTERY
    ...DECAL, WARNING - BATTERY
  • 6
    0645-082 ...WRAP, HEAT - BATTERY
    ...WRAP, HEAT - BATTERY
  • 7
    0645-161 CABLE, BATTERY/SOLENOID (INC. 8-9)
    CABLE, BATTERY/SOLENOID (INC. 8-9)
  • 8
    0645-019 ...BOOT, TERMINAL - BATTERY
    ...BOOT, TERMINAL - BATTERY
  • 9
    0645-327 ...BOOT, TERMINAL - SOLENOID
    ...BOOT, TERMINAL - SOLENOID
  • 10
    0645-080 CABLE, BATTERY/GROUND
    CABLE, BATTERY/GROUND
  • 11
    0645-244 CABLE, SOLENOID/STARTER MOTOR
    CABLE, SOLENOID/STARTER MOTOR
  • 12
    0645-196 SOLENOID (INC. 13-16)
    SOLENOID (INC. 13-16)
  • 13
    8043-452 ...NUT
    ...NUT
  • 14
    8051-242 ...WASHER, LOCK
    ...WASHER, LOCK
  • 15
    8042-272 ...NUT
    ...NUT
  • 16
    8051-152 ...WASHER, LOCK
    ...WASHER, LOCK
  • 17
    0745-149 TRAY, BATTERY
    TRAY, BATTERY
  • 18
    0645-245 STRAP, BATTERY
    STRAP, BATTERY
  • 19
    0645-243 STRAP, BATTERY
    STRAP, BATTERY
  • 20
    0623-325 NUT, WING
    NUT, WING
  • 21
    8050-217 WASHER
    WASHER
  • 22
    8047-366 NUT, LOCK
    NUT, LOCK
  • 23
    0716-391 CONDUIT, FLEXIBLE
    CONDUIT, FLEXIBLE
  • 24
    0645-181 TUBE, PROTECTION - HEAT
    TUBE, PROTECTION - HEAT
  • 25
    0623-589 CLIP, RETAINING (INCLUDED IN KIT)
    CLIP, RETAINING (INCLUDED IN KIT)
  • 26
    0123-788 CABLE TIE - 8 IN.
    CABLE TIE - 8 IN.
  • 27
    8020-045 SCREW, CAP
    SCREW, CAP
  • 27
    8020-040 SCREW, CAP
    SCREW, CAP
  • 28
    0686-695 HARNESS, ELECTRIC START (INC. 29-31) (INCLUDED IN KIT)
    HARNESS, ELECTRIC START (INC. 29-31) (INCLUDED IN KIT)
  • 29
    0630-100 ...FUSE, 7.5 AMP (INCLUDED IN KIT)
    ...FUSE, 7.5 AMP (INCLUDED IN KIT)
  • 30
    0630-002 ...DIODE, CHARGING (INCLUDED IN KIT)
    ...DIODE, CHARGING (INCLUDED IN KIT)
  • 31
    0123-811 ...CABLE TIE - 4 IN. (INCLUDED IN KIT)
    ...CABLE TIE - 4 IN. (INCLUDED IN KIT)
  • 32
    2611-744 DECAL, CONSOLE - RIGHT (INCLUDED IN KIT)
    DECAL, CONSOLE - RIGHT (INCLUDED IN KIT)
  • 33
    0609-449 SWITCH, IGNITION (INC. 34) (INCLUDED IN KIT)
    SWITCH, IGNITION (INC. 34) (INCLUDED IN KIT)
  • 35
    0123-899 WASHER, IGNITION (NOT INCLUDED IN KIT)
    WASHER, IGNITION (NOT INCLUDED IN KIT)
  • 36
    0609-113 NUT, RETAINING (INCLUDED IN KIT)
    NUT, RETAINING (INCLUDED IN KIT)
  • 37
    3611-644 DECAL, "ES" (INCLUDED IN KIT)
    DECAL, "ES" (INCLUDED IN KIT)
  • 38
    0623-144 CABLE TIE - 17.5 IN.
    CABLE TIE - 17.5 IN.
