HOOD- WINDSHIELD- AND FRONT BUMPER ASSEMBLY для Arctic Cat JAGUAR Z1 EARLY BUILD (GREEN) - 2007 года выпуска

  • №
    Артикул
    Название
  • 1
    2718-033 HOOD W/DECALS - GREEN (INC. 2-10)
    HOOD W/DECALS - GREEN (INC. 2-10)
  • 2
    7999-063 ...HOOD W/O DECALS - GREEN (INC. 3-8)
    ...HOOD W/O DECALS - GREEN (INC. 3-8)
  • 3
    4606-358 ......VENT, HOOD - OUTER FRONT - RIGHT
    ......VENT, HOOD - OUTER FRONT - RIGHT
  • 3
    4606-359 ......VENT, HOOD - OUTER FRONT - LEFT
    ......VENT, HOOD - OUTER FRONT - LEFT
  • 4
    4606-384 ......VENT, HOOD - OUTER REAR - RIGHT
    ......VENT, HOOD - OUTER REAR - RIGHT
  • 4
    4606-385 ......VENT, HOOD - OUTER REAR - LEFT
    ......VENT, HOOD - OUTER REAR - LEFT
  • 5
    3606-670 ......VENT, HOOD - INNER - RIGHT
    ......VENT, HOOD - INNER - RIGHT
  • 5
    3606-671 ......VENT, HOOD - INNER - LEFT
    ......VENT, HOOD - INNER - LEFT
  • 6
    1623-611 ......CLIP, RETAINING
    ......CLIP, RETAINING
  • 7
    1623-614 ......CLIP, RUBBER - HOOD HOLD-DOWN - RIGHT
    ......CLIP, RUBBER - HOOD HOLD-DOWN - RIGHT
  • 7
    1623-615 ......CLIP, RUBBER - HOOD HOLD-DOWN - LEFT
    ......CLIP, RUBBER - HOOD HOLD-DOWN - LEFT
  • 8
    1623-610 ......PIN, RETAINING
    ......PIN, RETAINING
  • 9
    7611-562 ...DECAL, HOOD - RIGHT
    ...DECAL, HOOD - RIGHT
  • 9
    7611-563 ...DECAL, HOOD - LEFT
    ...DECAL, HOOD - LEFT
  • 10
    7611-560 ...DECAL, HOOD - CREST
    ...DECAL, HOOD - CREST
  • 11
    3706-348 BRACKET, HINGE - RIGHT
    BRACKET, HINGE - RIGHT
  • 11
    3706-347 BRACKET, HINGE - LEFT
    BRACKET, HINGE - LEFT
  • 12
    1623-469 NUT, STAMPED
    NUT, STAMPED
  • 13
    3706-352 PANEL, SIDE - LOWER - FRONT - RIGHT
    PANEL, SIDE - LOWER - FRONT - RIGHT
  • 13
    3706-353 PANEL, SIDE - LOWER - FRONT - LEFT
    PANEL, SIDE - LOWER - FRONT - LEFT
  • 14
    1623-129 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 15
    4606-318 BEZEL, INTAKE - RIGHT
    BEZEL, INTAKE - RIGHT
  • 15
    4606-319 BEZEL, INTAKE - LEFT
    BEZEL, INTAKE - LEFT
  • 16
    3606-700 BASE, WINDSHIELD
    BASE, WINDSHIELD
  • 17
    4606-782 LATCH, WINDSHIELD - RIGHT
    LATCH, WINDSHIELD - RIGHT
  • 17
    4606-783 LATCH, WINDSHIELD - LEFT
    LATCH, WINDSHIELD - LEFT
  • 18
    1623-583 WASHER, RUBBER - WINDSHIELD LATCH
    WASHER, RUBBER - WINDSHIELD LATCH
  • 19
    4606-393 PLATE, BACKING - LATCH - LEFT
    PLATE, BACKING - LATCH - LEFT
  • 19
    4606-392 PLATE, BACKING - LATCH - RIGHT
    PLATE, BACKING - LATCH - RIGHT
  • 20
    1623-647 SCREW, THUMB
    SCREW, THUMB
  • 21
    3606-701 WINDSHIELD
    WINDSHIELD
  • 22
    4606-274 GROMMET
    GROMMET
  • 23
    3706-351 FASCIA, BUMPER - UPPER
    FASCIA, BUMPER - UPPER
  • 24
    3706-349 BUMPER, FRONT
    BUMPER, FRONT
  • 25
    4606-170 VENT, BUMPER - RIGHT
    VENT, BUMPER - RIGHT
  • 25
    4606-171 VENT, BUMPER - LEFT
    VENT, BUMPER - LEFT
  • 26
    3706-350 FASCIA, BUMPER - LOWER
    FASCIA, BUMPER - LOWER
  • 27
    0623-966 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 28
    0423-355 SCREW, SHOULDER
    SCREW, SHOULDER
  • 29
    8427-602 NUT, LOCK
    NUT, LOCK
  • 30
    0423-130 SCREW, BODY
    SCREW, BODY
  • 31
    8424-602 NUT
    NUT
  • 32
    0623-785 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
