DRIVE TRAIN SHAFTS AND BRAKE ASSEMBLIES для Arctic Cat BEARCAT WIDE TRACK TURBO (ARTICULATING) - 2007 года выпуска

  • №
    Артикул
    Название
  • 1
    0728-152 TRACK DRIVE ASSEMBLY (INC. 2-11)
    TRACK DRIVE ASSEMBLY (INC. 2-11)
  • 2
    1602-857 ...DRIVESHAFT
    ...DRIVESHAFT
  • 3
    1602-574 ...SPROCKET, DRIVE - INNER
    ...SPROCKET, DRIVE - INNER
  • 4
    1602-854 ...SPROCKET, DRIVE - OUTER
    ...SPROCKET, DRIVE - OUTER
  • 5
    1602-878 ...IDLER, CENTER
    ...IDLER, CENTER
  • 6
    0630-167 ...MAGNET, DISC
    ...MAGNET, DISC
  • 7
    0702-567 ...PLATE, FLANGE - BEARING ASSEMBLY (INC. 8-11)
    ...PLATE, FLANGE - BEARING ASSEMBLY (INC. 8-11)
  • 8
    8011-130 ......BOLT, CARRIAGE
    ......BOLT, CARRIAGE
  • 9
    0602-198 ......PLATE, FLANGE
    ......PLATE, FLANGE
  • 10
    1602-374 ......BEARING, 1 IN. W/LOCK COLLAR
    ......BEARING, 1 IN. W/LOCK COLLAR
  • 11
    0623-810 ......RING, SOLDER
    ......RING, SOLDER
  • 12
    3606-244 BRACKET, SENSOR
    BRACKET, SENSOR
  • 13
    0630-178 SENSOR, SPEEDOMETER
    SENSOR, SPEEDOMETER
  • 14
    0623-462 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 15
    8047-426 NUT, LOCK
    NUT, LOCK
  • 16
    1623-558 SCREW, CAP
    SCREW, CAP
  • 17
    1602-205 DISC, BRAKE
    DISC, BRAKE
  • 18
    0602-598 KEY
    KEY
  • 19
    0702-755 SHAFT, DRIVEN
    SHAFT, DRIVEN
  • 20
    0602-170 KEY
    KEY
  • 21
    1602-986 BEARING, 1 IN.
    BEARING, 1 IN.
  • 22
    2602-054 SLEEVE, ADAPTER W/NUT
    SLEEVE, ADAPTER W/NUT
  • 23
    2602-038 RING, RETAINING
    RING, RETAINING
  • 24
    0623-118 WASHER,FLAT-1.00 X1.43 X.030
    WASHER,FLAT-1.00 X1.43 X.030
  • 24
    0623-119 WASHER,FLAT-1.00 X1.43 X.075
    WASHER,FLAT-1.00 X1.43 X.075
  • 25
    2604-713 SPACER
    SPACER
  • 26
    0726-218 CLUTCH, DRIVEN
    CLUTCH, DRIVEN
  • 27
    0648-714 WASHER, DRIVEN .090 THICK
    WASHER, DRIVEN .090 THICK
  • 27
    0648-715 WASHER, DRIVEN .030 THICK
    WASHER, DRIVEN .030 THICK
  • 27
    0648-716 WASHER, DRIVEN .060 THICK
    WASHER, DRIVEN .060 THICK
  • 28
    0648-441 O-RING
    O-RING
  • 29
    0648-741 ADJUSTER, SHEAVE
    ADJUSTER, SHEAVE
  • 30
    0123-260 WASHER
    WASHER
  • 31
    0123-053 WASHER
    WASHER
  • 32
    1623-561 SCREW, CAP
    SCREW, CAP
  • 33
    0602-829 CALIPER, BRAKE - ASSEMBLY (INC. 34-44)
    CALIPER, BRAKE - ASSEMBLY (INC. 34-44)
  • 35
    0602-729 ...O-RING, HOUSING
    ...O-RING, HOUSING
  • 36
    0602-583 ...O-RING
    ...O-RING
  • 37
    0602-708 ...PISTON
    ...PISTON
  • 38
    0702-229 ...PAD, BRAKE - SET (INC. 39)
    ...PAD, BRAKE - SET (INC. 39)
  • 39
    0602-706 ......PIN, RETAINING
    ......PIN, RETAINING
  • 41
    0602-707 ...SCREW, BLEED - ASSEMBLY
    ...SCREW, BLEED - ASSEMBLY
  • 42
    0602-590 ...FITTING, ADAPTER
    ...FITTING, ADAPTER
  • 43
    8005-677 ...SCREW, CAP
    ...SCREW, CAP
  • 44
    8050-272 ...WASHER
    ...WASHER
