TUNNEL AND REAR BUMPER для Arctic Cat Z 440 SNO PRO (USA) - 2001 года выпуска

  • №
    Артикул
    Название
  • 1
    1718-051 TUNNEL ASSEMBLY (INC 2-6)
    TUNNEL ASSEMBLY (INC 2-6)
  • 2
    1606-926 BRACKET, SUSPENSION MOUNTING - RIGHT REAR
    BRACKET, SUSPENSION MOUNTING - RIGHT REAR
  • 2
    1606-927 BRACKET, SUSPENSION MOUNTING - LEFT REAR
    BRACKET, SUSPENSION MOUNTING - LEFT REAR
  • 3
    2706-139 EXTENSION, TUNNEL - FORMED
    EXTENSION, TUNNEL - FORMED
  • 4
    2706-138 PLATE, END - REAR TUNNEL
    PLATE, END - REAR TUNNEL
  • 5
    2706-160 ROLL, TUNNEL - RIGHT
    ROLL, TUNNEL - RIGHT
  • 5
    2706-161 ROLL, TUNNEL - LEFT
    ROLL, TUNNEL - LEFT
  • 6
    2706-124 PLATE, BACKING - RIGHT
    PLATE, BACKING - RIGHT
  • 6
    2706-125 PLATE, BACKING - LEFT
    PLATE, BACKING - LEFT
  • 7
    2706-048 BUMPER, REAR
    BUMPER, REAR
  • 8
    1706-005 SNOWFLAP
    SNOWFLAP
  • 9
    1606-712 STRAP, SNOWFLAP
    STRAP, SNOWFLAP
  • 10
    8061-506 RIVET
    RIVET
  • 11
    8060-808 RIVET
    RIVET
  • 12
    8061-708 RIVET
    RIVET
  • 13
    0623-759 WASHER
    WASHER
  • 14
    8041-366 NUT, LOCK
    NUT, LOCK
  • 15
    8050-157 WASHER
    WASHER
  • 16
    0623-797 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 17
    8017-610 SCREW, MACHINE
    SCREW, MACHINE
  • 18
    2606-302 PROTECTOR, TUNNEL
    PROTECTOR, TUNNEL
  • 19
    0623-784 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 20
    0623-166 RIVET
    RIVET
  • 21
    0623-167 PLUG, HOLE
    PLUG, HOLE
  • 22
    1606-676 BRACKET, SUPPORT - AIR SILENCER
    BRACKET, SUPPORT - AIR SILENCER
  • 23
    4611-090 DECAL, ''SNO PRO'' - SNOWFLAP
    DECAL, ''SNO PRO'' - SNOWFLAP
  • 24
    0411-053 DECAL, CE
    DECAL, CE
  • 25
    0707-710 BRACKET, HOSE HOLD-DOWN
    BRACKET, HOSE HOLD-DOWN
  • 26
    0606-029 REFLECTOR, REAR - RED
    REFLECTOR, REAR - RED
  • 27
    0623-269 CLIP, RETAINING
    CLIP, RETAINING
  • 28
    0123-418 RIVET
    RIVET
  • 29
    1606-713 PLASTIC EXTENSION
    PLASTIC EXTENSION
  • 30
    0706-371 TRIM
    TRIM
  • 31
    2706-116 PLATE, SUSPENSION MOUNTING - FRONT
    PLATE, SUSPENSION MOUNTING - FRONT
  • 32
    0623-072 RIVET, SOLID
    RIVET, SOLID
  • 33
    0623-806 RIVET, SOLID
    RIVET, SOLID
  • 34
    1706-162 VELCRO HOOK
    VELCRO HOOK
  • 35
    8060-706 RIVET
    RIVET
  • 36
    1611-566 DECAL, WARNING - TOWING (ENGLISH)
    DECAL, WARNING - TOWING (ENGLISH)
  • 37
    1611-567 DECAL, WARNING - TOWING (FRENCH)
    DECAL, WARNING - TOWING (FRENCH)
  • 38
    0716-973 WEARSTRIP
    WEARSTRIP
  • 39
    1606-718 BRACKET, MOUNTING - COIL
    BRACKET, MOUNTING - COIL
  • 40
    0623-833 SCREW, MACHINE
    SCREW, MACHINE
  • 41
    0623-779 INSERT
    INSERT
  • 42
    3611-888 DECAL, ''GENUINE ARCTIC CAT LUBRICANTS''
    DECAL, ''GENUINE ARCTIC CAT LUBRICANTS''
  • 43
    0623-562 PLUG, HOLE
    PLUG, HOLE
  • 44
    0623-305 PLUG, HOLE
    PLUG, HOLE
  • 45
    4611-369 DECAL, ''CROSS-LINK'' - TUNNEL
    DECAL, ''CROSS-LINK'' - TUNNEL
