DRIVE/REVERSE DROPCASE ASSEMBLY (ESR) (CONT) для Arctic Cat PANTHER 440 (ESR) - 2001 года выпуска

  • №
    Артикул
    Название
  • 1639-921 REVERSE OPTIONAL KIT HIGH/LOW ALT.
    REVERSE OPTIONAL KIT HIGH/LOW ALT.
  • 1
    1602-010 COVER, DROPCASE
    COVER, DROPCASE
  • 2
    0602-444 SPROCKET, 19T
    SPROCKET, 19T
  • 2
    0602-445 SPROCKET, 18T (INTERNATIONAL)
    SPROCKET, 18T (INTERNATIONAL)
  • 3
    0123-641 WASHER, FIBER
    WASHER, FIBER
  • 4
    0702-308 DROPCASE W/PLUGS
    DROPCASE W/PLUGS
  • 5
    0602-012 SPACER, SHAFT
    SPACER, SHAFT
  • 6
    1602-048 EXTENSION, DRIVESHAFT
    EXTENSION, DRIVESHAFT
  • 7
    0702-048 GEAR, REVERSE - 55T (INC. 8-10)
    GEAR, REVERSE - 55T (INC. 8-10)
  • 8
    0602-023 WASHER, THRUST
    WASHER, THRUST
  • 9
    0602-022 BEARING, THRUST
    BEARING, THRUST
  • 10
    0602-024 RING, RETAINING
    RING, RETAINING
  • 11
    0602-028 SPRING, RETURN
    SPRING, RETURN
  • 12
    0702-372 RETAINER, SHAFT (INC. 66)
    RETAINER, SHAFT (INC. 66)
  • 13
    8050-272 WASHER
    WASHER
  • 14
    8002-231 SCREW, CAP
    SCREW, CAP
  • 15
    1602-041 CHAIN, 70P
    CHAIN, 70P
  • 15
    1602-042 CHAIN, 72P (INTERNATIONAL)
    CHAIN, 72P (INTERNATIONAL)
  • 16
    0602-094 SHAFT, REVERSE
    SHAFT, REVERSE
  • 17
    0702-366 IDLER, REVERSE ASSEMBLY - 19T (INC. 65)
    IDLER, REVERSE ASSEMBLY - 19T (INC. 65)
  • 18
    0602-018 BEARING
    BEARING
  • 19
    0602-215 WASHER, THRUST (STD)
    WASHER, THRUST (STD)
  • 20
    8050-242 WASHER
    WASHER
  • 21
    8002-130 SCREW, CAP
    SCREW, CAP
  • 22
    0602-466 BRACKET, CHAIN BACKING
    BRACKET, CHAIN BACKING
  • 23
    0602-085 FORK, SHIFT
    FORK, SHIFT
  • 24
    0702-350 SHAFT, SHIFT FORK
    SHAFT, SHIFT FORK
  • 25
    0623-122 NUT, FLEX
    NUT, FLEX
  • 26
    0602-021 SEAL, O-RING
    SEAL, O-RING
  • 27
    0623-542 PIN, SPRING
    PIN, SPRING
  • 28
    1602-106 TUBE, OIL LEVEL STICK
    TUBE, OIL LEVEL STICK
  • 29
    0602-366 ALIGNER, IDLER - PIN
    ALIGNER, IDLER - PIN
  • 30
    1602-107 STICK, OIL LEVEL
    STICK, OIL LEVEL
  • 31
    0602-198 PLATE, FLANGE
    PLATE, FLANGE
  • 32
    0702-260 IDLER, REVERSE ASSEMBLY - 24T (INC. 18)
    IDLER, REVERSE ASSEMBLY - 24T (INC. 18)
  • 32
    0702-147 IDLER, REVERSE ASSEMBLY - 20T (INC. 18) (INTERNATIONAL)
    IDLER, REVERSE ASSEMBLY - 20T (INC. 18) (INTERNATIONAL)
  • 33
    8041-426 NUT, LOCK
    NUT, LOCK
  • 34
    8050-252 WASHER
    WASHER
  • 35
    0623-317 STUD, RIBBED
    STUD, RIBBED
  • 36
    0602-437 SEAL, DROPCASE
    SEAL, DROPCASE
  • 37
    0623-117 BOLT, RIBBED
    BOLT, RIBBED
  • 38
    0623-231 WASHER, SPRING
    WASHER, SPRING
  • 39
    0123-310 NUT, LOCK
    NUT, LOCK
  • 40
    0602-112 COVER, OIL VENT
    COVER, OIL VENT
  • 41
    0623-081 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 42
    0702-170 SPROCKET ASSEMBLY, 39T (INC. 43-49)
    SPROCKET ASSEMBLY, 39T (INC. 43-49)
  • 42
    0702-401 SPROCKET ASSEMBLY, 44T (INC. 43-49) (INTERNATIONAL)
    SPROCKET ASSEMBLY, 44T (INC. 43-49) (INTERNATIONAL)
  • 44
    0602-144 RETAINER, SPRING
    RETAINER, SPRING
  • 45
    0602-133 PIN, SLIP
    PIN, SLIP
  • 46
    0602-138 SPRING, COMPRESSION
    SPRING, COMPRESSION
  • 47
    0623-182 SCREW, CAP
    SCREW, CAP
  • 47
    0623-906 SCREW, CAP (INTERNATIONAL)
    SCREW, CAP (INTERNATIONAL)
  • 48
    0123-430 NUT, LOCK
    NUT, LOCK
  • 48
    0623-392 NUT, LOCK (INTERNATIONAL)
    NUT, LOCK (INTERNATIONAL)
  • 49
    0602-016 BEARING
    BEARING
  • 50
    0602-479 PLUG, DRAIN
    PLUG, DRAIN
  • 51
    1602-052 BEARING, 7/8 IN. W/O LOCK COLLAR
    BEARING, 7/8 IN. W/O LOCK COLLAR
  • 52
    1670-237 SEAL, O-RING
    SEAL, O-RING
  • 53
    0623-293 PLUG, DRAIN
    PLUG, DRAIN
  • 54
    1602-051 BEARING, 1 IN. W/O LOCK COLLAR
    BEARING, 1 IN. W/O LOCK COLLAR
  • 55
    8050-247 WASHER
    WASHER
  • 56
    8040-426 NUT, LOCK
    NUT, LOCK
  • 57
    8011-143 BOLT, CARRIAGE
    BOLT, CARRIAGE
  • 58
    0123-523 BOLT, RIBBED
    BOLT, RIBBED
  • 59
    8011-139 BOLT, CARRIAGE
    BOLT, CARRIAGE
  • 60
    0607-025 O-RING, STUD
    O-RING, STUD
  • 61
    8002-134 SCREW, CAP
    SCREW, CAP
  • 62
    8053-242 WASHER, LOCK - EXTERNAL TOOTH
    WASHER, LOCK - EXTERNAL TOOTH
  • 63
    8042-426 NUT
    NUT
  • 64
    1602-044 WASHER, THRUST
    WASHER, THRUST
  • 65
    1602-045 BEARING
    BEARING
  • 66
    8070-153 PIN, SPRING
    PIN, SPRING
  • 67
    1602-046 WASHER, TAB LOCK
    WASHER, TAB LOCK
  • 68
    1602-108 O-RING, OIL LEVEL STICK TUBE
    O-RING, OIL LEVEL STICK TUBE
  • 69
    0623-640 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 70
    0623-786 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 71
    0602-093 SPACER, REVERSE SHAFT (INTERNATIONAL)
    SPACER, REVERSE SHAFT (INTERNATIONAL)
  • 72
    0602-215 WASHER, THRUST (INTERNATIONAL)
    WASHER, THRUST (INTERNATIONAL)
