TRANSMISSION ASSEMBLY для Arctic Cat 150 UTILITY GREEN [A2016KYC2BUSZ] - 2016 года выпуска

  • №
    Артикул
    Название
  • 1
    3305-042 CHAIN, DRIVE
    CHAIN, DRIVE
  • 2
    3305-030 SPROCKET, DRIVE
    SPROCKET, DRIVE
  • 3
    3305-031 PLATE, RETAINING
    PLATE, RETAINING
  • 4
    3307-202 SCREW, CAP
    SCREW, CAP
  • 5
    3304-686 BOLT, FLANGE
    BOLT, FLANGE
  • 6
    3305-743 COVER, CHAIN
    COVER, CHAIN
  • 7
    3304-147 CIRCLIP, EXTERNAL - 25 MM
    CIRCLIP, EXTERNAL - 25 MM
  • 8
    3306-221 SHAFT, OUTPUT
    SHAFT, OUTPUT
  • 9
    3304-513 SHAFT, SHIFT FORK
    SHAFT, SHIFT FORK
  • 10
    3305-032 FORK, SHIFT
    FORK, SHIFT
  • 11
    3305-035 DRUM, GEAR SHIFT - ASSEMBLY (INC. TWO NO. 12 AND 13-14)
    DRUM, GEAR SHIFT - ASSEMBLY (INC. TWO NO. 12 AND 13-14)
  • 12
    3304-153 ...E-RING
    ...E-RING
  • 13
    3304-412 ...WASHER, THRUST
    ...WASHER, THRUST
  • 14
    3305-034 ...SPRING
    ...SPRING
  • 15
    3304-269 SPINDLE, DRUM SHIFT
    SPINDLE, DRUM SHIFT
  • 16
    3305-023 SHAFT, COUNTERBALANCE
    SHAFT, COUNTERBALANCE
  • 17
    3305-021 SHAFT, MAIN
    SHAFT, MAIN
  • 18
    3305-044 WASHER, THRUST
    WASHER, THRUST
  • 19
    3305-027 GEAR, REVERSE
    GEAR, REVERSE
  • 20
    3305-046 BEARING, NEEDLE
    BEARING, NEEDLE
  • 21
    3305-045 WASHER, SPLINED
    WASHER, SPLINED
  • 22
    3304-638 RING, RETAINING
    RING, RETAINING
  • 23
    3305-029 GEAR SELECT, SLIDING
    GEAR SELECT, SLIDING
  • 24
    3303-275 WASHER, THRUST - 15 MM
    WASHER, THRUST - 15 MM
  • 25
    3305-026 GEAR, FORWARD
    GEAR, FORWARD
  • 26
    3305-024 BUSHING
    BUSHING
  • 27
    3305-028 SPACER
    SPACER
  • 28
    3305-022 SHAFT, DRIVE
    SHAFT, DRIVE
  • 29
    3303-344 RING, RETAINING
    RING, RETAINING
