WIRING HARNESS ASSEMBLY для Arctic Cat XR 550 LTD BLACK [A2015XDO1PUSO] - 2015 года выпуска`
-
№АртикулНазвание
-
10486-512 HARNESS, MAIN (INC. 2-11)HARNESS, MAIN (INC. 2-11)
-
20486-164 ...TETHER, ACCESSORY CONNECTOR...TETHER, ACCESSORY CONNECTOR
-
30430-085 ...COVER, FUSE BLOCK...COVER, FUSE BLOCK
-
40430-045 ...RELAY (4-PIN) - 20 AMP...RELAY (4-PIN) - 20 AMP
-
50430-033 ...RELAY (5-PIN) - 30 AMP...RELAY (5-PIN) - 30 AMP
-
60430-037 ...HOLDER, FUSE...HOLDER, FUSE
-
70430-100 ...BREAKER, CIRCUIT - 15 AMP...BREAKER, CIRCUIT - 15 AMP
-
80430-032 ...FUSE - 10 AMP...FUSE - 10 AMP
-
80430-031 ...FUSE - 15 AMP...FUSE - 15 AMP
-
80430-030 ...FUSE - 30 AMP...FUSE - 30 AMP
-
94411-131 ...DECAL, FUSE BLOCK...DECAL, FUSE BLOCK
-
100430-086 ...SEAL...SEAL
-
110430-103 ...COVER, DIAGNOSTICS CONNECTOR...COVER, DIAGNOSTICS CONNECTOR
-
121436-487 REPAIR KIT, CONNECTOR - HEADLIGHTREPAIR KIT, CONNECTOR - HEADLIGHT
-
131436-416 REPAIR KIT, CONNECTOR - TILT SENSORREPAIR KIT, CONNECTOR - TILT SENSOR
-
142436-082 REPAIR KIT, CONNECTOR - TPS SENSORREPAIR KIT, CONNECTOR - TPS SENSOR
-
152436-081 REPAIR KIT, CONNECTOR - PS GAUGEREPAIR KIT, CONNECTOR - PS GAUGE
-
161436-484 REPAIR KIT, CONNECTOR - 4P - MAPREPAIR KIT, CONNECTOR - 4P - MAP
-
170530-129 BRACKET, MOUNTING - PDM - BLACKBRACKET, MOUNTING - PDM - BLACK
-
188476-612 SCREW, MACHINESCREW, MACHINE
-
190824-071 COIL, IGNITION - ASSEMBLY (INC. 20)COIL, IGNITION - ASSEMBLY (INC. 20)
-
200824-049 ...CAP, SPARK PLUG...CAP, SPARK PLUG
-
218468-425 SCREW, MACHINESCREW, MACHINE
-
220423-493 NUT W/WASHERNUT W/WASHER
-
230409-064 SENSOR, TILTSENSOR, TILT
-
240123-802 WASHERWASHER
-
250623-038 NUT W/WASHERNUT W/WASHER
-
260824-078 REGULATOR, VOLTAGEREGULATOR, VOLTAGE
-
278476-625 SCREW, MACHINESCREW, MACHINE
-
280530-131 ECMECM
-
291423-198 SCREW, MACHINESCREW, MACHINE
-
300123-788 TIE, CABLE - 8 IN.TIE, CABLE - 8 IN.
-
300123-903 TIE, CABLE - 11.5 IN.TIE, CABLE - 11.5 IN.
-
311423-270 TIE, CABLE - DOUBLE LOOP - 11 IN.TIE, CABLE - DOUBLE LOOP - 11 IN.
-
320430-102 CLIP, ROUTINGCLIP, ROUTING
-
330716-558 CONDUIT, PROTECTIVE - 10 FTCONDUIT, PROTECTIVE - 10 FT
