SECONDARY DRIVE ASSEMBLY для Arctic Cat WILDCAT BLACK [U2015W3W1PUSQ] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    0827-013 NUT
    NUT
  • 2
    0828-020 WASHER
    WASHER
  • 3
    0819-126 FLANGE, OUTPUT JOINT
    FLANGE, OUTPUT JOINT
  • 4
    0830-043 SEAL, OIL
    SEAL, OIL
  • 5
    0832-017 BEARING
    BEARING
  • 6
    0828-021 SHIM, 25 X 34 X 0.25 MM
    SHIM, 25 X 34 X 0.25 MM
  • 6
    0828-022 SHIM, 25 X 34 X 0.30 MM
    SHIM, 25 X 34 X 0.30 MM
  • 6
    0828-023 SHIM, 25 X 34 X 0.70 MM
    SHIM, 25 X 34 X 0.70 MM
  • 6
    0828-024 SHIM, 25 X 34 X 0.90 MM
    SHIM, 25 X 34 X 0.90 MM
  • 6
    0828-025 SHIM, 25 X 34 X 0.95 MM
    SHIM, 25 X 34 X 0.95 MM
  • 6
    0828-026 SHIM, 25 X 34 X 1.00 MM
    SHIM, 25 X 34 X 1.00 MM
  • 6
    0828-027 SHIM, 25 X 34 X 1.05 MM
    SHIM, 25 X 34 X 1.05 MM
  • 6
    0828-028 SHIM, 25 X 34 X 1.10 MM
    SHIM, 25 X 34 X 1.10 MM
  • 6
    0828-029 SHIM, 25 X 34 X 1.15 MM
    SHIM, 25 X 34 X 1.15 MM
  • 7
    0819-115 SHAFT, SECONDARY DRIVEN - FRONT
    SHAFT, SECONDARY DRIVEN - FRONT
  • 8
    0819-011 RING, DRIVEN BEARING
    RING, DRIVEN BEARING
  • 9
    0832-016 BEARING, DRIVEN GEAR
    BEARING, DRIVEN GEAR
  • 10
    0822-106 GEAR, SECONDARY DRIVEN
    GEAR, SECONDARY DRIVEN
  • 11
    0819-122 SHAFT, SECONDARY DRIVEN - REAR
    SHAFT, SECONDARY DRIVEN - REAR
  • 12
    0831-011 RING, RETAINING
    RING, RETAINING
  • 13
    0830-214 SEAL, OIL
    SEAL, OIL
  • 14
    0827-070 NUT
    NUT
  • 15
    0828-019 WASHER, THRUST
    WASHER, THRUST
  • 16
    0822-153 GEAR, SECONDARY DRIVE
    GEAR, SECONDARY DRIVE
  • 17
    0828-143 SHIM, 25.4 X 40 X 0.25 MM
    SHIM, 25.4 X 40 X 0.25 MM
  • 17
    0828-144 SHIM, 25.4 X 40 X 0.30 MM
    SHIM, 25.4 X 40 X 0.30 MM
  • 17
    0828-145 SHIM, 25.4 X 40 X 0.35 MM
    SHIM, 25.4 X 40 X 0.35 MM
  • 17
    0828-146 SHIM, 25.4 X 40 X 0.90 MM
    SHIM, 25.4 X 40 X 0.90 MM
  • 17
    0828-138 SHIM, 25.4 X 40 X 0.95 MM
    SHIM, 25.4 X 40 X 0.95 MM
  • 17
    0828-139 SHIM, 25.4 X 40 X 1.00 MM
    SHIM, 25.4 X 40 X 1.00 MM
  • 17
    0828-140 SHIM, 25.4 X 40 X 1.05 MM
    SHIM, 25.4 X 40 X 1.05 MM
  • 17
    0828-141 SHIM, 25.4 X 40 X 1.10 MM
    SHIM, 25.4 X 40 X 1.10 MM
  • 17
    0828-142 SHIM, 25.4 X 40 X 1.15 MM
    SHIM, 25.4 X 40 X 1.15 MM
  • 18
    0822-150 GEAR - 33T
    GEAR - 33T
  • 19
    0832-083 BEARING W/ SNAP RING
    BEARING W/ SNAP RING
  • 20
    0822-152 SHAFT, OUTPUT
    SHAFT, OUTPUT
  • 21
    0832-050 BEARING
    BEARING
