FRONT SUSPENSION ASSEMBLY для Arctic Cat WILDCAT BLACK [U2015W3W1PUSQ] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    0403-480 SHOCK ABSORBER - RIGHT (INC. 2-9)
    SHOCK ABSORBER - RIGHT (INC. 2-9)
  • 1
    0403-481 SHOCK ABSORBER - LEFT (INC. 2-9)
    SHOCK ABSORBER - LEFT (INC. 2-9)
  • 2
    0403-506 ...BEARING
    ...BEARING
  • 3
    0403-505 ...SPACER
    ...SPACER
  • 4
    0403-504 ...O-RING
    ...O-RING
  • 5
    0403-507 ...CLIP
    ...CLIP
  • 6
    8409-050 ...SCREW, CAP
    ...SCREW, CAP
  • 7
    8428-002 ...NUT, LOCK
    ...NUT, LOCK
  • 8
    0403-500 ...NUT, RETAINER - SPRING
    ...NUT, RETAINER - SPRING
  • 9
    0403-501 ...SCREW, SET
    ...SCREW, SET
  • 10
    0503-930 SPRING, SUSPENSION - WHITE
    SPRING, SUSPENSION - WHITE
  • 11
    0403-502 RETAINER
    RETAINER
  • 12
    0403-503 CLIP
    CLIP
  • 13
    0503-720 A-ARM, UPPER - RIGHT - BLACK (INC. 14-18)
    A-ARM, UPPER - RIGHT - BLACK (INC. 14-18)
  • 13
    0503-721 A-ARM, UPPER - LEFT - BLACK (INC. 14-18)
    A-ARM, UPPER - LEFT - BLACK (INC. 14-18)
  • 14
    0403-264 ...BUSHING
    ...BUSHING
  • 15
    1423-204 ...SEAL
    ...SEAL
  • 16
    0403-250 ...SLEEVE
    ...SLEEVE
  • 17
    0423-009 ...CLIP, BALL JOINT
    ...CLIP, BALL JOINT
  • 18
    0405-483 ...BALL JOINT
    ...BALL JOINT
  • 19
    0423-946 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 20
    0403-257 BRACKET, BRAKELINE
    BRACKET, BRAKELINE
  • 21
    8413-090 SCREW, CAP
    SCREW, CAP
  • 22
    0503-690 A-ARM, LOWER RIGHT - BLACK (INC. 14-18)
    A-ARM, LOWER RIGHT - BLACK (INC. 14-18)
  • 22
    0503-691 A-ARM, LOWER LEFT - BLACK (INC. 14-18)
    A-ARM, LOWER LEFT - BLACK (INC. 14-18)
  • 23
    1502-774 AXLE - FRONT - LOCKING (INC. 24-27)
    AXLE - FRONT - LOCKING (INC. 24-27)
  • 24
    2436-112 ...REPAIR KIT, BOOT (INC. 25)
    ...REPAIR KIT, BOOT (INC. 25)
  • 25
    1441-988 ......CLIP, RETAINING
    ......CLIP, RETAINING
  • 26
    1402-885 ...PIN, DETENT
    ...PIN, DETENT
  • 27
    1402-889 ...CLIP, RETAINING
    ...CLIP, RETAINING
  • 28
    0423-998 SCREW, SHOULDER
    SCREW, SHOULDER
  • 29
    0503-548 KNUCKLE - ASSEMBLY - RIGHT (INC. 30-31)
    KNUCKLE - ASSEMBLY - RIGHT (INC. 30-31)
  • 29
    0503-549 KNUCKLE - ASSEMBLY - LEFT (INC. 30-31)
    KNUCKLE - ASSEMBLY - LEFT (INC. 30-31)
  • 30
    1402-809 ...BEARING
    ...BEARING
  • 31
    0423-423 ...RING, RETAINING
    ...RING, RETAINING
